Analog Devices EVAL-LTC7063-AZ User Manual

150V Half-Bridge Driver with Floating Grounds and Adjustable Dead-Time

General Description

The EVAL-LTC7063-AZ evaluation circuit is a half-bridge
driver that drives two N-channel MOSFETs. The PWM
input control is 5V logic compatible and controls both gate
outputs, with one output being the complement of the
other. The eval kit has several unpopulated PCB pads to
help facilitate the user in customizing the board for their
application.
Performance Summary (T
PARAMETER
Logic Input Supply (VIN-LOGIC)
Power Input Supply (VIN-POWER)
Maximum Output Current
PWM Control Frequency
Maximum PWM Control Voltage

Quick Start Procedure

The EVAL-LTC7063-AZ can be evaluated without connecting any additional components or a load. However, the user
may find adding two load resistors, as shown in
can configure their own application circuit. Test with a resistor divider as a load:
1. Connect two 100Ω power resistors to the SW node, as shown in
2. Apply VIN-POWER supply.
3. Apply VIN-LOGIC supply.
4. Apply a square-wave signal at the desired frequency to the PWM pin, as shown in
5. Ensure the JP1 jumper is set to "ENABLED".
6. Monitor the BG, TG, and SW pins with a scope.
7. See Figure 2 for expected results with:
a. VIN-POWER = 40V
b. VIN-LOGIC = 10V
c. PWM input set at 5V peak at 1kHz
Rev 0
O n e A n a l o g Wa y , W i lm i ng t o n, M A 0 1 8 8 7 - 2 3 5 6 , U . S . A .
= 25°C)
A
CONDITIONS
Figure 1, provides a better means for evaluating. Alternatively, the user
DOCUMENT FEEDBACK
T e l : 7 8 1 . 3 2 9 . 4 7 0 0
Evaluation Board User Guide
EVAL-LTC7063-AZ
The LTC7063 driver has a powerful 0.8Ω pull-down and
1.5Ω pull-up MOSFET drivers driving two 150V N-channel
MOSFETs. The gate drivers on the LTC7063 are capable
of driving MOSFETs with different ground references;
however, this eval kit has these ground references
committed.
Design files for this circuit board are available.
MIN
6
Figure 1.
