DEMO MANUAL
EVAL-LTM4702-AZ
PERFORMANCE SUMMARY
PARAMETER
Input Voltage Range
Output Voltage
Maximum Output Current
Typical Switching Frequency
Typical Efficiency

QUICK START PROCEDURE

Evaluation board EVAL-LTM4702-AZ is easy to set up to
evaluate the performance of the LTM4702. See Figure 1
for the proper measurement equipment setup and follow
the procedure below.
1. With power off, connect the input power supply to V
(4V to 16V) and GND (input return).
2. Connect the 1V output load between V
(Initial load: no load).
3. Connect the DVMs to the input and output. Set default
jumper position:
JP1: FCM
JP2: 120 PS
2
Specifications are at T
CONDITIONS
V = 4V to 16V, I = 0A to 8A
IN OUT
V = 4V to 16V
IN
V = 12V, I = 8A
IN OUT
and GND
OUT
ON
ON
= 25°C
A
MIN
4
4. Turn on the input power supply and check for the
proper output voltage. V
5. Once the proper output voltage is established, adjust
the load within the operating range and observe
the output voltage regulation, efficiency, and
IN
other parameters.
NOTE: When measuring the output or input voltage rip-
ple, do not use the long ground lead on the oscilloscope
probe. See Figure 2 for the proper scope probe technique.
Short, stiff leads may be soldered to the (+) and (–) ter-
minals of an output capacitor. The probe's ground ring
needs to touch the (–) lead, and the probe tip needs to
touch the (+) lead.
TYP MAX
16
1 ±2%
8
800
80.5
should be 1V ±2%.
OUT
VALUE
V
V
A
kHz
%
Rev. 0
