Levitronix PuraLev i100MU User Manual page 5

System Name Article #
PuraLev-i100MU.1 100-91227
PuraLev-i100MU.4 100-91228
PuraLev-i100MU.9 100-91513
PuraLev-i100MU.8 100-91512
PuraLev-i100MU.2 100-91229
PuraLev-i100MU.5 100-91230
PuraLev-i100MU.3 100-91231
PuraLev-i100MU.6 100-91232
Pos. Component Article Name
1a LPP-200.17
(With drain port)
Multi-Use
Pump Heads
1c LPP-200.16
(No drain port)
Integrated Pump
2a IPD-100.1-50-03
Driver ("OEM Model")
Integrated Pump
Driver ("EasyConnect"
2b IPD-100.4-03
Model)
Integrated Pump
Driver ("Stand-Alone"
2c IPD-100.6-03
Model)
Integrated Pump
Driver ("OEM ATEX"
2d IPD-100.10-50-03
Model)
Autoclaving
3 ART-200.1
Reinforcing Tool
Note 1: Designed and tested for IP67.
Pos. Component Article Name
4a AC/DC Power Supply TSP 180-124 (Traco)
Desktop AC/DC
4b GST160A24-R7B IC915
Power Supply
AMC-1.1 (2m)
AC Mains Cables AMC-1.2 (2.5m)
4c AMC-1.3 (2.5m)
(for Desktop power
AMC-1.4 (2.5m)
supply 5b)
AMC-1.5 (2.5m)
USB to RS485
5 YN-485I-TR
Adaptor-TR Isolated
IPS Cable Power 2
6 ICP-2.1-50 (5 m)
Wires
ICS-1.1-02 (0.2 m)
IPS Cable Signal 6
7a ICS-1.1-10 (1 m)
Wires
ICS-1.1-30 (3 m)
IPS Cable Signal 6
7b ICS-1.2-50 (5 m)
Wires
IPS Cable Signal 12
8 ICS-2.1-50 (5 m)
Wires
Fieldbus Termination
9 FTC-1.1
Connector
10 User Panel LUI-B.1-01
ATEX Cable ACS-A.1
11
Sealing System (Roxtec)
PL-4075-00, Rev02, DCO# 20-275
Pump Head Driver
LPP-200.16
IPD-100.1-50-03
LPP-200.17 (Drain port)
LPP-200.16
IPD-100.10-50-03
LPP-200.17 (Drain port)
LPP-200.16
IPD-100.4-03
LPP-200.17 (Drain port)
LPP-200.16
IPD-100.6-03
LPP-200.17 (Drain port)
Table 1: Standard driver system configurations
Article # Characteristics
Impeller / Pump Housing
Housing Sealing O-Ring
In-/Outlet Fittings
100-90864
Max. Flow
Max. Diff.-Pressure
Max. Viscosity
100-90863
Wet Pump Vol./Surface
Max. Liquid Temp.
Sterilization Methods
Voltage, Power
Housing / Cable
100-10134
Interfaces
Standard Firmware
Housing
100-10135 Interfaces
Standard Firmware
Housing
100-10136
Interfaces
Standard Firmware
Housing / Cable
Interfaces
100-10202
ATEX / IECEx Marking
Standard Firmware
Purpose
190-10280 Material
Mounting Screws
Table 2: Specification of standard components
Note 2: For serial pumping as one unit according to Figure 6 special firmware is available on request.
Article # Characteristics
Voltage Output / Input
100-40018 Basic Dimensions
Certification or Standards
Voltage Output / Input
Basic Dimensions
100-40020
Safety Approvals
Note
Approvals and Country
190-10331
Approvals and Country
190-10332
Approvals and Country
190-10333
Approvals and Country
190-10334
Approvals and Country
190-10335
Cable Specifications
Structure/Design
100-30392
Purpose
Cable Material / Wires
190-10370
Connection In / Out
Main Purpose
190-10381
Cable Material / Wires
190-10344 Connection In / Out
Main Purpose
190-10345
Cable Material / Wires
190-10346
Connection In / Out
Main Purpose
Cable Material / Wires
190-10347
Connection In / Out
Main Purpose
Materials
190-10348
Main Purpose
Interface / Housing Rating
100-30448
Standard Firmware
Sleeve (A) and Gasket (B)
100-90292 Frame (C)
2x Cable Module (D)
Table 3: Specification of accessories
Note 1: Designed and tested for IP67.
User Manual for PuraLev
Note
OEM - Driver, 5 m PVC cable with open wires, pump head socket.
OEM ATEX - Driver, 5 m FEP cable with open wires, pump head socket.
EasyConnect - Driver with interface connectors, pump head socket.
Stand-Alone - Driver with integrated user panel, pump head socket.
Value / Feature
PFA/PVDF (FDA, USP Class VI, BSE/TSE/Animal free)
Triclamp EPDM (FDA, USP VI, Animal/BSE/TSE free)
Triclamp ½" for in/outlet, Triclamp ½" for drain port (BS-4825-3)
17.4 liters/min / 4.6 gallons/min
2.4 bar / 35 psi
< 20 cP
2
26 ml / 158 cm (without drain port)
70 °C / 158 °F
CIP (clean in place), Autoclaving, SIP
24 VDC ±10%, 110 W
Epoxy coated Alu., PP bottom lid, IP65 1 / PVC jacket, open wires, cable length 5 m
PLC and RS485 with Modbus protocol
G9.48
Epoxy coated Aluminum, PP for bottom lid, IP65
2x Fieldbus RS485 with Modbus protocol, PLC and power supply
G9.48 2
Epoxy coated Aluminum, PP for bottom lid, IP65
User panel with 3 user buttons, PLC and power supply
G9.48
ETFE coated Alu., IP65 1 / FEP jacket, open wires, cable length 5 m
PLC and RS485 with Modbus protocol
II 3G Ex ec h mc IIC T4 Gc /
G9.48
Stabilization of pump housing during autoclaving
Anodized Aluminum
4 pcs M3 x 14 mm (Stainless steel)
Value / Feature
85 – 132 and 187 – 264 VAC (autoselect)
24 VDC with 120 W /
110 x 110 x 54 mm (mountable on DIN rail 35 mm)
UL/cUL, CB, Semi F47
85 – 264 VAC, 47-63 Hz
24VDC, 160W /
175 x 72 x 35 mm
UL60950-1, CSA C22.2, TUV EN60950-1
Connector for direct connection to power supply of driver with cable length 1.2 m.
UL, cUL, US, Canada
CB, Germany, Denmark, Norway, Finland, Belgium, Netherl., Sweden, Austria
PSE, Japan
Switzerland
CE, United Kingdom
Black color, ROHS
USB connector (A) with termination resistor and cable (2m) with connector pair (B
and C) for external RS485 wire connection. Magnetically isolated. Cable length is
2m. Included is a USB space saver cable (D).
Communication over fieldbus of driver with PC
PVC jacket / 2x 1.5 mm 2
Open wires / Circular Intercontec type to driver
Connection of power supply to "Stand-Alone" and "EasyConnect" drivers
PVC jacket / 6x 0.08 mm 2 and shielding
Circular Hirose type / Circular Hirose type
Fieldbus connection between "EasyConnect" drivers (e.g. multi-pump arrays)
PVC jacket / 6x 0.08 mm 2 and shielding
Connector with screw type plug for open wire connection / Circular Hirose type
Fieldbus connection to "EasyConnect" drivers and to PLC of "Stand-Alone" drivers.
2
PVC jacket / 12x 0.14 mm and shielding
Connector with screw type plug for open wire connection / Circular Hirose type
General connection to PLC of "EasyConnect" drivers.
PPS for connector housing and FPM for sealing.
Termination of fieldbus.
RS485 / IP65
A3.00
Stainless Steel and EPDM
Roxylon (EPDM rubber)
Roxylon (EPDM rubber)
®
i100MU
www.levitronix.com
3
II 3D Ex h tc IIIC T90°C Dc
Note:
Lubricant (E) and measurement plates
(F) are included.
