point ORBIT ONE User Manual page 16

DISMOUNTING AND CLEANING OF THE APPLIANCE
The following dismounting and cleaning should be done after the disconnection
of the power supply!
Dismounting and mounting of the roller brush
Step 1: Dismount the roller brush.
Overturn the appliance, remove the
roller brush box release button
toward the center, dismount the
main body roller brush housing, take
out the roller brush and remove any
matters on its surface.
Dismounting and mounting of side brush
Step 1: Dismount the side brush.
Overturn the appliance, remove the
screws with help of a screwdriver
and dismount the side brush.
CAUTION
1. Replace the old side brush with a standard one for a good cleaning effect.
2. Remove the side brush with a screwdriver carefully to avoid injuries.
3. The cleaning brush has a sharp blade for cutting twining articles difficult to remove.
4. Keep it out of reach of children.
Roller brush
box release
button
16
Step 2: Clean the roller brush.
Use the cleaning brush to lift and
cut off the hair and other fibers on
the roller brush and separate them
from the roller brush. It is suggested
to replace the roller brush every
three to six months.
Step 2: Clean the side brush.
Use the cleaning brush to lift and
cut off the hair and other fibers on
the side brush and separate them
from the side brush. It is suggested
to replace the side brush every three
to six months.
