EVAL-ADG5209FEBZ User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 3.
Reference Designator
A0, A1, EN
C3, C4, C7, C8
C1, C2
C5, C6
DA, DB
GND1, GND2
J1, J2, J5
J3, J4
R2, R5, R8, R11, R12, R17, R20, R23,
R26, R29, R31, R33, R35, R38, R41
R1, R3, R4, R6, R7, R9, R10, R16, R18,
R19, R21, R22, R24, R25, R27, R28, R30,
R37, R39, R40, R42
R32, R34, R36
R14, R15
R13
S1A, S2A, S3A, S4A, S1B, S2B, S3B, S4B,
SW1, SW2, SW3
T1, T2, T3, T4, T5, T6, T7, T8, T9, T10
T_A0, T_A1, T_EN
U1
U2
1 N/A means not available.
Description
50 Ω, straight, SMB jack
50 V, X7R, 0603 size, 0.1 µF, multilayer
ceramic capacitor
50 V, tantalum, D size, 10 µF capacitor
Ceramic, multilayer, 4.7 µF capacitor
50 Ω, SMB socket
Black test point
4-pin terminal block (5 mm pitch)
2-pin terminal block (5 mm pitch)
0603, 1%, 0 Ω resistor
SMD, 0603 resistor
1 kΩ, 0.063 W, 1%, 0603, resistor
0805, 1%, 0 Ω resistor
SMD, 0805 resistor
50 Ω, SMB socket
Single-pole, double throw (SPDT), SMT
slide switch
Red test point
Red test point
Fault protection, −0.4 pC Q
INJ
4:1 multiplexer
Linear regulator, 5.0 V, LDO
Rev. 0 | Page 11 of 12
Manufacturer Part
Number 1
SMB1251B1-3GT30G-50
GRM188R71H104KA93D
TAJD106K050RNJ
C2012X5R1H475K125AB
SMB1251B1-3GT30G-50
20-2137
CTB5000/4
CTB5000/2
MC0063W06030R
N/A
MC0063W060311K
MC01W08050R
N/A
SMB1251B1-3GT30G-50
CAS-120TA
20-313137
20-313137
, dual ADG5209FBRUZ
ADP7142AUJZ-5.0
UG-875
Stock Code
FEC 1111349
FEC 882-0023
FEC 143-2387
FEC 2346932
Do not insert
FEC 873-1128
FEC 151791
FEC 151789
FEC 9331662
Do not insert
FEC 9330380
FEC 9333681
Do not insert
Do not insert
Digi-Key CAS120JCT-ND
FEC 873-1144
FEC 873-1144
ADG5209FBRUZ
ADP7142AUJZ-5.0-R7
