SECTION VII - SUPERVISOR KEY ACCESS
Man Issue Limit
Key/Card Override
Require Logon Script:
Agency Quantity Multiplier
Descriptive Product Prompting
Multiple Product Auth
Display Last Transaction
Print Receipt Date And Time
Print MPC Description
Passive Mobile Mode
System Options are set by Syn-Tech Systems, Inc., before shipping the
FuelMaster® Unit. Subsequent changes in the System Options may be
made by calling Syn-Tech's Customer Help Desk.
TESTS
CONFIG >
TESTS:1=SW,2=OUTS,3=LCD,4=KEYPAD,5=RCPT,
6=BOARDS,A=PROKEE,B=COUNT,C=RESET,D=EXIT
CONFIG > TESTS >
The switch test, when performed, affirms that the FuelMaster® unit
is detecting when the pump handle is turned on and when the
manual mode switches are in auto or manual.
• PH - The 8-1 line corresponds with PUMPS H-A. A 1 in the hose
position indicates that the pump handle is on. At the same time, the
LEDs marked pump handle on the pedestal I/O board blink as the
pump handles are turned on.
NOTE:
SWITCH (SW)
SWITCH TEST: PH-87654321 MM-87654321
D=EXIT TEST 00000000
250, Unlimited
Enabled/Disabled
Enabled/Disabled
Enabled/Disabled
Enabled/Disabled
Enabled/Disabled
Enabled/Disabled
Enabled/Disabled
Enabled/Disabled
Enabled/Disabled
00000000
52
