Syn-Tech Systems FuelMaster Plus Operation Manual page 19

SECTION II- USER KEY OPERATIONS
Enter the miles or hours (without tenths) on the FMU keypad. Once
entered, press the ENTER/YES on the keypad. Unlike the Vehicle
Key system, no check is made on this miles/hour entry; it is
recorded with the transaction.
If the Oil Check option is enabled, the following prompt is displayed:
This prompt requests that the 'YES' or 'NO' key on the FMU keypad be
pressed based on whether the oil has been checked at the time of this
fueling transaction or not. Press 'YES' or 'NO' and the following prompt is
displayed:
This prompt requires entry of a single digit between 0 and 9 on the
FMU keypad (there is an option to enter a two digit number if need
be). Enter the number of quarts of oil added at the time of this
fueling transaction and press <ENTER>.
The oil check transaction will appear as a separate transaction on the
FMU's on-site printer and in the Central Controller's transaction listing but
will appear at the bottom of the fuel transaction receipt on the FMU's
receipt printer. This feature is added as an additional record keeping
capability of FuelMaster systems.
Once all of the entries have been completed, the following hose selection
display appears:
REMOVE KEY, SELECT HOSE, PRESS <ENTER>
This selection is limited to those hoses with the same product
code(s) authorized for the User Key. Select the hose of choice and
press ENTER/YES.
An asterisk (*) next to a hose number means that this hose is
***** FUELMASTER *****
DID YOU CHECK YOUR OIL? (Y/N) --->
***** FUELMASTER *****
ENTER OIL QTY ADDED (QUARTS) --->
NOTE:
1, 2, 3, 4, 5, 6, 7, 8 --->
NOTE:
19
