SECTION VI - TANKER TRUCK OPERATIONS
keypad. This number is assigned to the key when it is encoded and is a 4-digit
number that is unique to the key. If the PIN entry is incorrect, an error message is
displayed and the process begins again. Upon entry of a valid PIN entry, the next
prompt appears.
REMOVE KEY, SELECT HOSE, PRESS <ENTER>
1,2,3,4 --->
The hose selection is limited to the hoses that have the same product code(s) as
those authorized for the Tanker Key. Select the hose and press ENTER/YES.
Once a hose is selected, one of two messages appears on the FMU display.
These messages depend upon the type of dispenser installed how it was wired
during installation of the FuelMaster® hardware:
*** DISPENSER ACTIVATED ***
*** DISPENSE PRODUCT ***
This prompt appears if the FMU configuration is set to Pump Handle Detect - NO.
It does not matter when the pump handle is turned on. When this message
appears, the FMU is ready to track fueling.
<<< TURN ON PUMP HANDLE TO DISPENSE >>>
<<< THE SELECTED PRODUCT >>>
This prompt appears if the FMU configuration is set to Pump Handle Detect -
YES. It indicates that the FMU is ready to watch for the pump handle to be turned
on.
The prompt then indicates the dispenser hose status.
>>> DISPENSER HAS BEEN ACTIVATED <<<
>>> RETURN HOSE AFTER USE <<<
When the FMU sees the pump handle turned on, it responds with the above
message and is ready to track fueling.
** PUMP HANDLE NOT TURNED OFF **
** PLEASE TURN PUMP HANDLE OFF! **
The FMU could not detect when the pump handle was turned on because it was
