Evaluation Board User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Reference Designator
C1
C2, C4, C6, C8
C3, C5, C7
C9, C10
C11, C14, C15, C16, C26
C12
1
C13
C17, C20
C18, C21
C19, C22
C27
D1
D2
D3
1 1
J1, J2, J3, J4, J5, J6, J7
J9
LK1, LK2
P1
1 1 1
R1, R2, R3, R4, R13
R5, R11
R6
R7
R8 to R10
R12, R14, R22 to R24
R15
1
R16
R17
R18
SW1
T1 to T3, T5 to R7, T11, T12
T4
U1
U2, U3
1
Y1
1
Do not insert.
Part Description
22 μF capacitor, Case A, 6.3 V, RTAJ_A
10 pF capacitor, 0603, 50 V
0.1 μF capacitor, 0603, 16 V
1 nF capacitor, 0603, 50 V
100 pF capacitor, 0603, 50 V
220 pF capacitor, 0603
Capacitor, 0603
1 μF capacitor, Case A, 25 V, RTAJ_A
4.7 μF capacitor, Case A, 10 V, RTAJ_A
10 nF capacitor, 0603, 25 V
2.7 nF capacitor, 0603
6.2 V diode Schottky, 20 V, 400 mW, DO35, SD103C
1 A diode, 50 V, DO35
LED, LED_SMT
Conn jack end launch PC gold SMA, SMA_CARD_EDGE_RF
Plug, D PCB R/A T&D, 25-way, DB9-HM, CON-DB9HM
Header, 1 row vertical, 3-way and jumper socket, LINK-3P_TEXT_INV, JUMPER2\SIP3
Battery clip, PCB mounting, BATT_PP3
0 Ω resistor, 0603
51 Ω resistor, 0603
4.7 kΩ resistor, 0603
Resistor, 0603 10 kΩ, 0 Ω
18 Ω resistor, 0603
330 kΩ resistor, 0603
4.7 kΩ resistor, 0805
Resistor, 0603
3 kΩ resistor, 0603
6.2 kΩ resistor, 0603
Switch, PCB, SPDT SW_SIP-3P, SW_POWER
Terminal, PCB red, test point
Terminal, PCB black, test point
ADF4108 PLL frequency synthesizer, 20-lead LFCSP
ADP3300 low dropout linear regulator, 6-lead SOT-23
10.0 MHz OSC_TCXO
Rev. 0 | Page 7 of 8
UG-160
