ORDERING INFORMATION

BILL OF MATERIALS

Table 5.
Item Qty Reference Designator
1 5 C1, C2, C10, C11, C12
2 3 C13, C14, C31
3 2 C15, C16
4 6 C18, C19, C20, C23, C35, C36
5 2 C21, C22
6 3 C24, C44, C46
7 1 C29
8 2 C33, C34
9 19 C3, C4, C5, C6, C8, C9, C17, C25,
C26, C27, C28, C30, C32, C37,
C38, C41, C42, C43, C45
10 2 C39, C40
11 1 C7
12 2 D1, D2
13 1 D3
14 1 D4
15 2 D5, D6
16 1 J1
17 1 J2
18 1 J3
19 1 J4
20 2 J5, J6
21 1 J7
22 1 J8
23 7 L1 to L7
24 1 Q1
25 1 Q2
Description
Multilayer ceramic 50 V, NP0
(0402), 1.0 nF
Multilayer ceramic 16 V, X7R
(0402), 56 nF
SMD tantalum capacitor SMD,
N 6.3 V, 220 μF
Multilayer ceramic 10 V, X7R
(0805), 10 μF
Tantalum capacitor 105° SMD,
100 μF
SMD tantalum capacitor 6.3 V,
(0805), 10 μF
Multilayer ceramic 50 V, X7R
(0402), 3.3 nF
Multilayer ceramic 50 V, NP0
(0402), 100 pF
Multilayer ceramic 16 V, X7R
(0402), 0.10 μF
Multilayer ceramic 50 V, NP0
(0402), 22 pF
SMD tantalum capacitor 6.3 V,
(0805), 15 μF
Schottky 30 V, 0.5 A, SOD123
diode
Green diffused 10 mcd, 565 nm
(1206)
Red diffused 6.0 mcd, 635 nm
(1206)
Yellow diffused 4.0 mcd,
585 nm 1206
Not populated (open)
Mini power jack 0.08" R/A TH
2-pin header unshrouded
jumper 0.10"; use shunt Tyco
881545-2
Connector terminal block,
2.54 mm, 4 position, 20 - 26
awg screw clamp
Stereo mini jack, SMT
8-way, unshrouded header,
dual row, 2 × 4
10-way, shroud polarized
header, 2 × 5
Chip ferrite bead 600 Ω @
100 MHz
PNP transistor, 40 V, 3 A, SOT-23
NPN transistor, GP, 40 V, SOT-23
Rev. 0 | Page 10 of 12
Manufacturer Part Number
Murata ENA GRM1555C1H102JA01D
Kemet C0402C563K4RACTU
Nichicon F930J227MNC
Murata ENA GRM21BR71A106KE51L
Kemet T520B107M004ATE035
Rohm TCP0J106M8R
Panasonic EC ECJ-0EB1H332K
Murata ENA GCM1555C1H101JZ13D
Panasonic EC ECJ-0EX1C104K
Murata ENC GRM1555C1H220JZ01D
Rohm TCP0J156M8R
On Semiconductor MBR0530T1G
Lumex Opto SML-LX1206GW-TR
Lumex Opto SML-LX1206IW-TR
CML Innovative Tech CMD15-21VYD/TR8
Switchcraft, Inc. RAPC722X
Sullins Electronics Corp. PBC02SAAN
Phoenix Contact 1725672
CUI, Inc. SJ-3523-SMT
Sullins Electronics Corp PBC04DAAN
3M N2510-6002RB
TDK Corp. MMZ1005S601C
Zetex, Inc. ZXTP25040DFHTA
Micro Commercial Co. MMBT2222A-TP
