Danfoss FT1330 Crimp Machine Operator's Manual
Barrel Crimp Die Cage
FT1330-2-9-51
DETAIL NUMBER
1
2
3
4
5
6
7
8
9
11
12
13
13
14
17
18
AQ439269212774en-000101
PART NUMBER
FT1330-2-9-1
FT1330-2-9-2
FT1330-2-9-3
FT1330-2-9-4-2
FT1330-2-9-5
FT1330-2-9-6
FT1330-2-9-7
FT1330-2-9-8
FT1330-2-9-9
FT1330-2-9-10
FT1330-2-9-11
FT1330-250-0016
FT1330-250-0012
FT1330-2-9-12
FT1330-275-12
FT1330-285-16
DESCRIPTION
Roll Pin
Spring
Spring Plate
Front Plate
Button Head Cap Screw
Spacer
Nut
Back Plate
Button Head Cap Screw
Button Head Cap Screw
Lock Nut
Locator Tab
Locator Tab
Bumper Grommet
Locator Tab Adapter
Locator Tab Adapter
© Danfoss FT1330 Crimp Machine Operator's Manual | 2023.02. | 51
NUMBER REQUIRED
8
8
1
1
3
4
1 -
1
1
2
2
1
1
2
1
1
