Danfoss FT1330 Operator's Manual page 42

Model B Cylinder Subassembly
DETAIL NUMBER
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
42 | © Danfoss FT1330 Crimp Machine Operator's Manual | 2023.02.
PART NUMBER
FT1330-2-8-1
FT1330-2-8-2
FT1330-2-8-3
FT1330-2-3-4
FT1330-2-3-5
FT1330-2-8-6
FT1330-2-8-7
FT1330-2-3-8
FT1330-2-8-9
FT1330-2-8-10
FT1330-2-8-11
FT1330-2-8-12
FT1330-2-8-13
FT1330-2-3-14
FT1330-2-8-15
FT1330-2-8-16
FT1330-2-8-17
FT1330-2-8-18
FT1330-2-8-19
Danfoss FT1330 Crimp Machine Operator's Manual
DESCRIPTION
Slyde Ring TJ#7881 -4
Head Blind End TJ #TG52KAB072
Piston TJ #TG53KAB073
Crimp Ring TJ #TX86HG3384
Crimp Insert TJ #TX86HG3384A
Piston Rod TJ #TG82UAB072
Hex Nut TJ #5063-18
Rod Wiper TJ #5026-3
Rod Seal TJ #7623-011
O-Ring Seal TJ #5145-339
GFT Seal TJ #5160-0500
Square Steel TJ #5222-2468
Slyde Ride TJ #7880-1
Retaining Ring TJ #5194-625
Body TJ #TG57KAB072
O-Ring Seal TJ #5145-248
Back Up Ring TJ #5138-AA263
Tie Rod TJ #TX56LAB072
Flat Washer TJ #5060-AB072
NUMBER REQUIRED
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
2
4
AQ439269212774en-000101
