Danfoss FT1330 Crimp Machine Operator's Manual
Global Crimp Die Cage
DETAIL NUMBER
1
2
3
4
5
6
7
8
AQ439269212774en-000101
PART NUMBER
FT1330-2-9-9
FT1330-2-9-21
FT1330-2-9-13
FT1330-2-9-14
FT1330-2-9-55
FT1330-2-9-66
FT1330-2-9-7
FT1330-2-9-18
DESCRIPTION
1/4-20 X 2.5 Screw
Spring
Spring Plate
Front Plate
Button Head Cap Screw
Spacer
Nut
Back Plate
© Danfoss FT1330 Crimp Machine Operator's Manual | 2023.02. | 45
NUMBER REQUIRED
1
16
1
1
3
4
1
1
