Danfoss FT1330 Crimp Machine Operator's Manual
Flat Field Crimp Die Cage
FT1330-2-9-0004
DETAIL NUMBER
1
2
3
4
5
6
7
8
9
11
12
13
14
FT1330-2-9-0608
DETAIL NUMBER
1
2
3
4
5
6
7
8
9
11
12
13
14
AQ439269212774en-000101
PART NUMBER
FT1330-2-9-1
FT1330-2-9-2
FT1330-2-9-3
FT1330-2-9-4-5
FT1330-2-9-5
FT1330-2-9-6
FT1330-2-9-7
FT1330-2-9-8
FT1330-2-9-9
FT1330-2-9-10
FT1330-2-9-11
FT1330-250-0004
FT1330-2-9-12
PART NUMBER
FT1330-2-9-1
FT1330-2-9-2
FT1330-2-9-3
FT1330-2-9-4-6
FT1330-2-9-5
FT1330-2-9-6
FT1330-2-9-7
FT1330-2-9-8
FT1330-2-9-9
FT1330-2-9-10
FT1330-2-9-11
FT1330-250-0608
FT1330-2-9-12
DESCRIPTION
Roll Pin
Spring
Spring Plate
Front Plate
Button Head Cap Screw
Spacer
Nut
Back Plate
Button Head Cap Screw
Button Head Cap Screw
Lock Nut
Locator Tab
Bumper Grommet
DESCRIPTION
Roll Pin
Spring
Spring Plate
Front Plate
Button Head Cap Screw
Spacer
Nut
Back Plate
Button Head Cap Screw
Button Head Cap Screw
Lock Nut
Locator Tab
Bumper Grommet
© Danfoss FT1330 Crimp Machine Operator's Manual | 2023.02. | 49
NUMBER REQUIRED
8
8
1
1
3
4
1
1
1
1
1
1
1
NUMBER REQUIRED
8
8
1
1
3
4
1
1
1
1
1
1
1
