Danfoss FT1330 Crimp Machine Operator's Manual
Crimp Die Cage
DETAIL NUMBER
1
2
3
4
5
6
7
8
AQ439269212774en-000101
PART NUMBER
FT1330-2-9-9
FT1330-2-9-2
FT1330-2-9-3
FT1330-2-9-4-1-1
FT1330-2-9-5
FT1330-2-9-6
FT1330-2-9-7
FT1330-2-9-8
DESCRIPTION
1/4-20 X 2.50 Screw
Spring
Spring Plate
Front Plate
1/4-20 x 2.00 Screw
Spacer
Nut
Back Plate
