Danfoss FT1330 Operator's Manual page 36

115 Volt Electrical Schematic
DETAIL NUMBER
1
2
3
4
5
6
7
8
9
10
Note: Fuse holder is allied part number 845-4219 or equivalent.
36 | © Danfoss FT1330 Crimp Machine Operator's Manual | 2023.02.
PART NUMBER
FT1330-2-5-1
FT1330-2-5-2
FT1330-2-5-3
FT1330-2-5-4
FT1330-2-5-5
FT1330-2-5-6
FT1330-2-5-7
FT1330-2-5-8
FT1330-2-5-9
FT1330-2-5-10
Danfoss FT1330 Crimp Machine Operator's Manual
DESCRIPTION
Manual Motor Starter
Fuse
Transformer
Foot Switch
Push Button, Contact Block, Legend Plate
Linear Transducer With Connector
3 Digit Knobpot
Control Card
Card Connector
Resistor
NUMBER REQUIRED
1
1
1
1
1
1
1
1
1
1
