Agrowtek GrowControl GCX Instruction Manual page 99

Temperature & Humidity Settings
Settings for temperature and humidity can be scheduled and con gured on the rules tab.
Multiple rules can be created; each rule may have di erent set points.
Temperature and humidity controls each have two stages. Activation of the second stage is managed by a
"stage separation" value. Preview charts depict the sensor readings at which equipment will start and stop.
Modify the set point values until the previews show the setpoints the way you would like them to operate.
Temperature Control
Temperature is managed by heating and cooling set points. Heating and cooling both have two stage
control; stages are separated by a "stage separation" value. Set points and deadbands have slightly di erent
meanings depending on whether they are for heating or cooling.
1
2
3
1. Temperature Control
2. Heating Settings
3. Cooling Settings
4. Preview
Heating
Set Point (SP) Temperature to heat to.
Deadband (DB) Temperature drop before heating.
Stage Separation Temperature below SP to start stage 2.
99
Settings group for the temperature control parameters.
Set point, dead band and stage separation values for heating.
Set point, dead band and stage separation values for cooling.
Shows a preview of how the heating or cooling function will operate.
© Agrowtek Inc. | www.agrowtek.com | Technology to Help You Grow™
Cooling
Temperature to start cooling at.
Temperature drop to stop cooling.
Temperature above SP to start stage 2.
4
