Adding & Editing Controls
Controls functions are added to a workspace by pressing the desired toolbar button. An un-named function
will be added to the workspace.
Press on the new function icon in the workspace to open the function editor and con gure the function.
Function Editor
The function editor will open when a function icon within the workspace area is pressed. A header at the top
of the editor contains a name eld and several buttons to copy, delete and save the function as well as exit
the editor window.
Two tabs at the below the top header separate the settings for the RULES Two tabs at the below the top header separate the settings for the RULES
settings. Equipment settings apply to all rules in the function.
The RULES tab where parameters are con gured for
the function in rules.
52
© Agrowtek Inc. | www.agrowtek.com | Technology to Help You Grow™
and for the EQUIPMENT and for the EQUIPMENT
The EQUIPMENT tab where inputs and outputs are
speci ed for the function to control.
