Agrowtek GrowControl GCX Instruction Manual page 53

Function Editor Header
The function editor has a header at the top of the window with a name for the function and several buttons
to copy, delete and save the rule. The close the cuntion editor, use the exit door button in the upper right
1
1. Show in Report If checked the control function status will be shown on the home page report.
2. Function Name Press the [ X ] button to delete the name or press the text eld to edit the name.
3. Report Switch Enable this switch to show the status of the function in the home screen reports.
4. Copy Function Opens a dialog to make a copy of the current function; select a workspace to copy to.
5. Delete Function Opens a dialog to delete the current control function from the workspace.
6. Save Settings Press the save button to save the changes to the system memory.
The save button will be highlighted green when settings on the page have changed.
7. Exit Editor Closes the editor dialog and returns to the workspace.
If changes have been made and are not saved before exiting they will be lost.
Copy a Function
To copy a function with all of the existing rules to a new or the same workspace, use the copy function
button at the top of the function editor window. A dialog will prompt for the destination workspace.
Delete a Function
If a function is no longer required or has been created accidentally, open the function editor for the function
to be removed by pressing on the function icon in the workspace. In the editor window press on the delete
function button. A dialog will appear asking to con rm you wish to delete the function and rules.
53
2
© Agrowtek Inc. | www.agrowtek.com | Technology to Help You Grow™
3 4 5 6 7
