System Commands; System Date & Time - Agrowtek GrowControl GCX Instruction Manual

System Commands

The system commands group includes buttons for accessing the clock con guration dialog, update dialog,
cpu status dialog, system console and system reboot/shutdown options.
1. Set Clock Opens the system clock/time zone dialog window.
2. Check Updates Opens the updater dialog to check the internet for system updates.
3. Restart Opens a dialog to restart the GrowControl system app or reboot the operating system.
4. Shut Down Shuts down and powers o the GCX controller. (Requires power cycle to restart.)
5. CPU Status Displays information and statistics about the main system processor.
6. Screen Test Test dialog to check touch screen controller operation.
7. Load Firmware Opens the AgrowLINK updater utility for loading rmware on GrowNET™ devices.
System Date & Time
The system time zone can be set so that the system reports the correct time for your geographic location.
Time is automatically updated from the internet when there is a connection, otherwise the time and date
can be manually con gured from this dialog. To access the dialog, press the "SET CLOCK" button in the Sys-
tem commands group on the System Settings page.
3
1. Time Zone Set the local time zone for the GCX system.
2. Time Manual system time con guration (only when internet connection is unavailable.)
3. Date Picker Manual system date con guration (only when internet connection is unavailable.)
34
1 2
5 6
© Agrowtek Inc. | www.agrowtek.com | Technology to Help You Grow™
3 4
7
1
2
