Nutrient Parts
Nutrient parts are entered in a fashion similar to most manufacturer's recipe recommendations in ml/gal.
Alternative units are also available.
Each nutrient part may be named for reference and assigned to a dosing "group. " Parts that are assigned to
the same group will dose at the same time. Otherwise, parts will dose sequentially in order of their group as-
signment. Nutrient parts will be mated with the dosing pumps in the dosing function according to the order
in the part list (1).
1
1. Nutrient Part List
2. Part Name
3. Dosing Group
4. Dose Size
5. Mix Delay
6. Sort Buttons
7. Delete Part
8. Add Part
TIP
The smallest dose that the ADi-200 pumps can produce is 3ml. Recipes with parts smaller than 3ml will have
the entire recipe multiplied automatically to produce a minimum dose of 3ml when dosing.
91
2
List of all the nutrient parts in the recipe. Select a part to edit the values.
Reference name of the recipe part.
Select a group for the nutrient part; groups are dosed sequentially.
Dose size per manufacturer recipe (ml/gal.)
Delay after dosing before moving to the next group.
Move the selected part up or down in the list.
Delete the selected part from the list.
Add a new part to the list.
