Hydroponics Sensors (SXH, GXH, PHX)
Sensor # Type
1 Temperature
2 pH
3 Conductivity
4 O.R.P.
5 D.O.
6 Flow
Input Modules (DXI8)
Type
Voltage
Current
Calibration Registers
O set Calibration
O set (zero) calibration is an arithmatic positive or negative correction to the sensor reading and is the only
type of sensor calibration available on climate/environmental sensors. To perform a sensor o set calibration,
write the correct sensor value to the o set calibration regsiter (consider the integer scaling noted.)
Span Calibration
Span, or slope calibration, corrects the slop of the sensor reading at a second point, away from the zero cali-
bration. Operations performed using the span register are:
-pH 4.01 or 10.0 calibration
-Conductivity, ORP or DO calibration to solution standard
Environment Sensors (SXC, SXE)
Parameter Description
Temperature
Humidity
Calibration Input,
O set (Zero)
Light
CO2
Hydroponics Sensors (SXH, PHX)
Parameter Description
Temperature
pH
Calibration Input,
Zero
Conductivity
O.R.P. / D.O.
pH
Calibration Input,
Conductivity
Span
O.R.P. / D.O.
114
Integer Scale
x100
x100
x1
x1
x100
x10
Integer Scale
x1
x100
Range
See integer ranges.
Range
See integer ranges.
See integer ranges.
© Agrowtek Inc. | www.agrowtek.com | Technology to Help You Grow™
Range
-2000 - 6000 (-20 - 60°C)
0 - 1400 (0 - 14.00pH)
0 - 2500 ppm
-1000 - +1000 mV
0 - 2000 (0 - 20.00 mg/L)
0 - 125 gpm
Range
0 - 5000 mV
0 - 2000 (0 - 20 mA)
Type
16 bit, signed
Type
16 bit, signed
16 bit, signed
Access Address
41101
41102
W
41103
41104
Access Address
41101
41102
W
41103
41104
41202
W 41203
41204
