Agrowtek GrowControl GCX Instruction Manual page 75

Shade / Blackout Curtain Mode
This mode is designed to control shade curtains and black-out curtains using the static position option.
Shade mode will reduce the %open position in the solar shading and temperature shading modes in an
e ort to reduce solar radiation resulting in excess heat. Shading from high intensity light can reduce solar
heating or when the interior temperature is too high can help alleviate excess heat.
Additional positions for high light intensity, high temperature and weather alarms can also be con gured to
actively adjust the position depending on conditions.
NOTE: To enable a sensor based position option, turn on the appropriate switch on the equipment tab
and assign a sensor. Once the assignments are saved, the settings will be shown.
1
2
3
4
1. Temperature Position
2. Temperature Limit
3. Solar Position
4. Solar Limit
75
Maximum %open position when limit is exceeded.
Temperature high limit; if reached, the position limit is activated.
If temperature is high, the shade will reduce %open to the selected position.
Maximum %open position when limit is exceeded.
Light intensity high limit; if reached, the position limit is activated.
If intensity is high, the shade will reduce %open to the selected position.
