Day & Night Mode
Each control group workspace has a dedicated "day & night" function that can be con gured to operate
based on time of day, or light intensity levels from a light sensor. The day & night mode function is a power-
ful and simple way to coordinate functions in your workspaces according to the status of day or night.
To con gure a function to be active only during the day or night, enable the "Day & Night" switch:
The Day/Night mode control is located in the bottom tool bar of each controls work space.
Press the button to display the editor dialog and adjust the rules for day & night.
Day and night time can be simply scheduled with a morning and evening time of day, or multiple rules can
be created to schedule the day/night to adjust based on the date range or day number count. Day and night
can also be coordinated with a light sensor to set the state based on the intensity of light.
2
4
5
1. Current Status Shows the current status of the day/night control function.
2. Rules Tab Edit the day/night schedule rules on this tab.
3. Equipment Tab Edit the sunlight sensor selection (optional) on this tab.
4. Rule Name Each rule can be named for reference.
5. Rule List Select a rule in the list to edit.
6. Rule Schedule If desired, the rule can be restricted to a date range or day number range.
7. Time Range Set the day time and night time values if using a time range.
8. Sunlight Settings Set points for light sensor based day/night control (optional.)
61
© Agrowtek Inc. | www.agrowtek.com | Technology to Help You Grow™
1
3
6
7
8
