Southbend EH-10CCH Installation & Operation Manual

Marathoner gold half-size electric convection ovens
Hide thumbs Also See for EH-10CCH:

Advertisement

Quick Links

Installation & Operation Manual
Marathoner Gold Half-Size
Electric Convection Ovens
EH-10CCH, EH-10SC, EH-10TC
EH-20CCH, EH-20SC & EH-20TC
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury
or death. Read the installation, operating and maintenance instructions thoroughly before installing or
M
1184093 Rev 4 (01/23)
ANUAL
$21.00
Model EH-10TC
servicing this equipment.
1100 Old Honeycutt Road Fuquay-Varina, North Carolina 27526 USA
www.southbendnc.com
WARNING
SOUTHBEND
A Middleby Company
Marathoner Gold Half-Size Electric Convection Ovens
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #: ___________________________
Serial #: ___________________________
Date Purchased: _____________________
Model EH-20SC
M
ANUAL
S
CO
ECTION
