Hardware Installation and Reference Guide
1.3

Package Contents

Table 1-3 Package contents
Name
Master AP
Mounting plate
Wall anchor
Phillips pan head tapping screw 4.2*20
Hardware Installation and Reference Guide
1.4

Product Technical Specifications

1.4.1

Dimensions and Weight

Table 1-4 Dimensions and weight description
Parameter Name
Product dimensions (W x D x H)
Weight
Mounting mode
Security lock
Mounting plate dimensions (W x
D x H)
Mounting plate hole interval
Mounting plate hole diameter
Value
230 mm x 230 mm x 51 mm
Master AP: 1.0 kg
Mounting plate: 0.1 kg
Ceiling and wall-mounted
Dormant lock, hanging lock
120 mm x 120 mm x 8 mm
53 mm x 53 mm. For the diagram of mounting plate, see
Preparation.
6.5 mm
4
Quantity
1
1
4
4
1
