3. Press Enter to show the RAID array details.
RAID Mode : Striping
Striping Width: 2
RAID Mode : Striping
Adapt Channel
0 0
0 0
2 1
2 0
[F6] Back [F7] Finish [TAB] Navigate [
[R] Rebuild
4. Finally press Enter again to return the previous screen and press
[Ctrl+X] to exit and reboot the system.
Congratulations! RAID mode 0+1 with 2xIDE Hard Disks and 2xSATA
Hard Disks is successfully built in the Array Disks.
NVIDIA RAID Utility
Array 2 : NVIDIA STRIPE
- Define a New Array -
- Array Detail -
M/S Index Disk Model Name
Master 0
Slave 1
Master 2
Master 2
[D] Delete [C] Clear Disk [ENTER] Return
