SOLTEK SL-65ME-T User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

R
T h e
S o u l
O f
C o m p u t e r
T e c h n o l o g y
Mainboard
SL-65ME-T/65ME+-T
User Manual V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL-65ME-T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SOLTEK SL-65ME-T

Summary of Contents for SOLTEK SL-65ME-T

  • Page 1 T h e S o u l C o m p u t e r T e c h n o l o g y Mainboard SL-65ME-T/65ME+-T User Manual V1.0...
  • Page 2 Every effort has been made to ensure that the information in this manual is accurate. Soltek Computer Inc. is not responsible for print- ing or clerical errors. Information in this document is subject to change without notice and does not represent a commitment on the part of Soltek Computer Inc.

  • Page 3: Soltek Computer Inc

    SOLTEK AROUND THE WORLD SOLTEK COMPUTER INC. Address : 7F, No. 306-3, Ta-Tung Rd, Sec.1, Hsi-Chih, Taipei- Hsien, Taiwan, R.O.C. Telephone : 886-2-2642-9060 : 886-2-2642-9065 E-mail : sales@soltek.com.tw Web site : http://www.soltek.com.tw SOLTEK KOREA INC. Address : 1002, Chung Jin Bldg. 53-5 Wonhyo-Ro, 3-Ka,...

  • Page 4: Table Of Contents

    65ME-T/ME+-T CONTENT Chapter 1 Introduction ..............8 1-1 Mainboard Specification ................ 9 1-1.1 Processor ......................9 1-1.2 Chipset ......................9 1-1.3 AWARD BIOS V6.0, Supporting ..............9 1-1.4 Full Featured Accelerated Graphics Port (AGP) Controller ......9 1-1.5 Sound Controller .................... 9 1-1.6 Integrated SDRAM Controller ..............
  • Page 5 Content 2-4.2 JP5/JP6 Bus Clock Select ................24 2-4.3 BIOS Boot Block Lock (JP16) ..............25 2-4.4 JP21 On-Board Creative Sound Select (For 65ME+-T Only) ..... 25 2-4.5 JBAT1/JBAT2 For Clear CMOS DATA ............26 2-5 Connectors Configurations ..............27 2-5.1 On Board FAN Connector (CPUFA1, AUXFA1, CHAFA1) .......
  • Page 6 65ME-T/ME+-T 3-6 AC’97 Audio Driver Installation (For 65ME-T Only) ......50 3-7 Proceed To Hardware Monitor Utility Installation ......51 Chapter 4 BIOS Setup ..............54 4-1 What Is BIOS Setup ................55 4-2 How To Run BIOS Setup ..............55 4-3 What Is CMOS ..................

  • Page 7: Item List Checkup

    Chapter 1 Introduction ITEM LIST CHECKUP Mainboard ==== Support CD ==== User’s Manual ==== Bundled Bonus Pack CD ==== Bundled Bonus Pack Manual ==== Temperature Sensor Cable ==== ATA66/100 IDE Cable ==== RS232 Cable FDD Cable...

  • Page 8: Chapter 1 Introduction

    65ME-T/ME+-T Chapter 1 Introduction • This chapter briefly introduces this characteristics of the mainboard. It includes the information regarding the chipset, CPU types, built-in functions and layout. Users will have more ideas about mainboards after reading this chapter. This chapter contains the following topics : 1-1 Mainboard Specification 1-2 Mainboard Layout 1-3 Chipset Diagram...

  • Page 9: Mainboard Specification

    Chapter 1 Introduction 1-1 Mainboard Specification 1-1.1 Processor ® • Supporting Intel FC-PGA Pentium III up to 1GHz. • Supporting Intel ® FC-PGA 370 Celeron up to 1.1GHz. ® • Supporting Intel FC-PGA2 processors. ® • Supporting VIA Cyrix III up to 800MHz.

  • Page 10: 1-1.6 Integrated Sdram Controller

    65ME-T/ME+-T 1-1.6 Integrated SDRAM Controller • Providing 3pcs DIMM slots for double-sided DIMMs. • Supporting 100/133MHz SDRAM spec. • Supporting total memory from 32MB to 512MB using 32Mb/64Mb/128Mb/ 256Mb technology. • Supporting up to 3 double sided DIMMs at 100MHz system memory bus. •...

  • Page 11: 1-1.9 Power Management

    Chapter 1 Introduction 1-1.9 Power Management • ACPI 1.0 compliant (Advanced Configuration and Power Interface). • APM V1.2 compliant (Legacy power management). • Supporting POS mode (Power On Suspend). • System event monitoring with two event classes. • Supporting PS/2 Keyboard & Mouse power on. •...

  • Page 12: Mainboard Layout

    65ME-T/ME+-T 1-2 Mainboard Layout 1-2.1 Mainboard Layout --- 65ME-T CPUFA1 ATX POWER Clock Generator Intel 82815 GMCH AUXFA1 AGP 4X AC'97 Codec CD_IN1 PCI 1 CD_IN2 Intel PCI 2 ICH2 JBAT1 PCI 3 JBAT2 JP16 PCI 4 Battery PCI 5 Controller USB1 SCR1...

  • Page 13: 1-2.2 Mainboard Layout

    Chapter 1 Introduction 1-2.2 Mainboard Layout --- 65ME+-T CPUFA1 ATX POWER Clock Generator Intel 82815 GMCH AUXFA1 AGP 4X CD_IN1 PCI 1 CD_IN2 TAD1 Intel PCI 2 ICH2 JBAT1 PCI 3 JBAT2 JP16 PCI 4 Battery PCI 5 Controller JP21 USB1 SCR1 CNR1...

  • Page 14: Chipset System Block Diagram

    65ME-T/ME+-T 1-3 Chipset System Block Diagram Intel Pentium III Processor Intel Celeron Processor System Bus (66/100/133MHz) Digital Display Digital Video Out Intel 82815 Chipset Encoder 64bit / Intel 82815 100/133MHz System B-stepping Memory (GMCH) -Memory Controller Analog Display -AGP Controller AGP Connector -Graphics Controller -3D Engine...

  • Page 15: Mainboard Specificationtable Of 65Me-T & 65Me+-T

    Chapter 1 Introduction 1-4 Mainboard SpecificationTable Of 65ME-T & 65ME+-T Model 65ME-T 65ME+-T Memory Intel 82815 B-stepping (GMCH) Controller Hub Intel 82801BA (ICH2) Controller Hub LPC I/O Chip ITE 8712 Supports PC133 and PC100 SDRAM up to 512GB Memory 3 DIMM Slots AGP Interface AGP 4X Pro Mode Audio...
  • Page 16 65ME-T/ME+-T MEMO MEMO...

  • Page 17: Chapter 2 Hardware Setup

    Chapter 2 Hardware Setup Chapter 2 Hardware Setup ATTENTION !!! 1. Please refer to your processor installation or other documentation attached to your CPU for more detailed installing instruction. 2. Installing a heat sink and cooling fan is necessary for proper heat dissipation from your CPU.

  • Page 18: Cpu Installation

    65ME-T/ME+-T 2-1 CPU Installation WARNING !!! • Make sure that +5V DCV and +3.3 DCV of your power supply are suitable for the processor. • Any attempt to operate the Celeron or PIII processor without a suitable cooling Fan will damage processor and other component. Pull out the lever from the socket, and then raise the lever up to a 90-degree angle.

  • Page 19: Memory Installation

    Chapter 2 Hardware Setup 2-2 Memory Installation WARNING!!! • Make sure to unplug your power supply before adding or removing memory modules or other system components. Failure to do so may cause severe damage to both your mainboard and expansion cards. •...

  • Page 20: 2-2.1 Supported System Bus And System Memory Bus Frequencies Table

    65ME-T/ME+-T 2-2.1 Supported System Bus And System Memory Bus Frequencies Table • The 82815 B-stepping MCH has a new type of clocking architecture. It has integrated SDRAM buffers that run at either 100 or 133 MHz, independent of the system bus frequency. See table below for supported system bus and system memory bus frequencies of 82815 B-stepping.

  • Page 21: Hdd/Fdd Installation

    Chapter 2 Hardware Setup 2-3 HDD/FDD Installation • To install HDD (Hard Disk Drive), you may connect the cable’s blue connector to the mainboard’s primary (IDE1) or secondary (IDE2) connector, and then connect the gray connector to your slave device and the black connector to your master device.
  • Page 22 65ME-T/ME+-T • To install FDD (Floppy Disk Drive), you may connect the end with single connector to the board , and connect the other and with two plugs to the floppy drives. CPUFA1 ATX POWER Clock Generator Intel 82815 GMCH AUXFA1 Floppy Disk Drive Connector: AGP 4X...

  • Page 23: Jumper Setting For Devices On Board

    Chapter 2 Hardware Setup 2-4 Jumper Setting For Devices On Board • The following diagrams show the locations of jumper blocks on the mainboard. CAUTION • Do not remove the jumper when power is on. Always make sure the power is off before changing any jumpers. Otherwise, mainboard could be damaged.

  • Page 24: 2-4.2 Jp5/Jp6 Bus Clock Select

    65ME-T/ME+-T 2-4.2 JP5/JP6 Bus Clock Select JP5/JP6 settings for FSB (Front Side Bus) Frequency Select is a redundancy device designed for professional CPU overcolocking only. Since this mainboard is designed with CPU clock auto-detection function, you are recommended to use the JP5/JP6 default setting for a stable system performance.

  • Page 25: 2-4.3 Bios Boot Block Lock (Jp16)

    Chapter 2 Hardware Setup 2-4.3 BIOS Boot Block Lock (JP16) CPUFA1 ATX POWER Clock Generator BIOS Boot Block Lock: Intel Locked 82815 GMCH JP16 AUXFA1 AGP 4X Unlocked (default) CD_IN1 PCI 1 JP16 CD_IN2 TAD1 Intel PCI 2 ICH2 JBAT1 PCI 3 JBAT2 JP16...

  • Page 26: 2-4.5 Jbat1/Jbat2 For Clear Cmos Data

    65ME-T/ME+-T 2-4.5 JBAT1/JBAT2 For Clear CMOS DATA A battery should be used to supply the power for the CMOS RAM to retain the mainboard configuration. CPUFA1 ATX POWER Clock Generator Intel 82815 JBAT1/JBAT2 For Clear GMCH CMOS DATA: AUXFA1 AGP 4X AC'97 Codec CD_IN1...

  • Page 27: Connectors Configurations

    Chapter 2 Hardware Setup 2-5 Connectors Configurations • This section list out all connectors configurations for users’ reference. 2-5.1 On Board FAN Connector (CPUFA1, AUXFA1, CHAFA1) +12V CPUFA1 ATX POWER SENSOR Clock Generator O n B o a r d FA N C o n n e c t o r (CPUFA1): O n B o a r d FA N C o n n e c t o r (AUXFA1):...

  • Page 28: 2-5.2 Jwol1 Wake On Lan

    65ME-T/ME+-T 2-5.2 JWOL1 Wake On LAN CPUFA1 ATX POWER Clock Generator +5V standby Intel 82815 GMCH AUXFA1 AGP 4X Wake On LAN: AC'97 Codec CD_IN1 PCI 1 CD_IN2 Intel Connect the Wake PCI 2 ICH2 On LAN signal from JBAT1 PCI 3 JBAT2 JP16...

  • Page 29: 2-5.3 Cd-Rom Audio Connector (Cd_In1/Cd_In2)

    Chapter 2 Hardware Setup 2-5.3 CD-ROM Audio Connector (CD_IN1/CD_IN2) CPUFA1 ATX POWER CD_IN1 Clock Generator CD_IN2 CD-ROM Audio Connector: Intel 82815 CD_IN1 CD_IN2 PIN NO. GMCH AUXFA1 AGP 4X Left PIN 1 AC'97 Channel Codec CD_IN1 PCI 1 CD_IN2 Left Intel PCI 2 PIN 2...

  • Page 30: 2-5.4 Tad1/Tv1 Connector

    65ME-T/ME+-T 2-5.4 TAD1/TV1 Connector CPUFA1 ATX POWER TAD1 Clock Generator TAD1/TV1 Connector: Intel PIN NO. TAD1 82815 GMCH TV_L AUXFA1 PIN 1 PHONE AGP 4X CHANNEL CD_IN1 PCI 1 CD_IN2 TAD1 PIN 2 Intel PCI 2 ICH2 JBAT1 PCI 3 JBAT2 JP16 PIN 3...

  • Page 31: 2-5.5 Thermal Sensor Connector (Rt2)

    Chapter 2 Hardware Setup 2-5.5 Thermal Sensor Connector (RT2) CPUFA1 ATX POWER Thermal Sensor Connector Clock Generator (RT2): Intel 82815 GMCH AUXFA1 AGP 4X AC'97 Codec CD_IN1 PCI 1 CD_IN2 Intel PCI 2 ICH2 JBAT1 PCI 3 JBAT2 JP16 PCI 4 Battery PCI 5 Controller...

  • Page 32: 2-5.6 Complex Header J2&J3

    65ME-T/ME+-T 2-5.6 Complex Header J2&J3 • This complex Header consists of 10 connectors providing various supports: J2J3 15 15 SUSPEND LED SMI SIGNAL SUSPEND LED SIGNAL POWER SWITCH ATX POWER SWITCH KEYLOCK CONNECTOR KEYLOCK SIGNAL POWER LED NO CONNECTION NO CONNECTION INFRARED(IR) INFRARED TRANSMIT SIGNAL INFRARED TRANSMIT SIGNAL...

  • Page 33: 2-5.7 Atx Power Supply Connector

    Chapter 2 Hardware Setup 6. J3 Keylock Connector: CONNECTION: Connected to keylock switch. FUNCTION : To lock keyboard for security purpose. 7. J3 Power LED Connector: CONNECTION: Connected to System Power LED. FUNCTION : To supply power to “System Power LED”. 8.

  • Page 34: 2-5.8 Chassis Panel Connector

    65ME-T/ME+-T 2-5.8 Chassis Panel Connector A : PS/2 MOUSE PORT B : USB 0 PORT C : LPT1 PORT D : GAME/MIDI PORT E : PS/2 KEYBOARD PORT F : USB 1 PORT G : COM1 PORT H : VGA PORT : LINE OUT/ SPEAKER OUT PORT J : LINE IN (or second speaker out for 65ME+ only)

  • Page 35: 2-5.9 Serial Port Connector

    Chapter 2 Hardware Setup 2-5.9 Serial Port Connector • One serial port is ready for a mouse or other serial devices. A second serial port is available using a serial port bracket connected from the mainboard to an expansion slot opening. CPUFA1 ATX POWER Clock...

  • Page 36: 2-5.10 Smart Card Reader Connector (Scr1)

    65ME-T/ME+-T 2-5.10 Smart Card Reader Connector (SCR1) • The connector “SCR1” allows you to use Smart Card Reader. It is compliant with Personal Computer Smart Card (PC/SC) working group standard and smart card (ISO 7816) protocols. CPUFA1 ATX POWER Clock Generator Intel 82815...

  • Page 37: 2-5.11 Communication And Networking Riser Slot (Cnr)

    Chapter 2 Hardware Setup 2-5.11 Communication And Networking Riser Slot (CNR) • This connector allows you to use network, modem or audio riser cards. CPUFA1 ATX POWER Clock Generator Intel 82815 GMCH AUXFA1 AGP 4X AC'97 Codec CD_IN1 PCI 1 CD_IN2 Intel PCI 2...

  • Page 38: 2-5.12 Usb1 Header

    65ME-T/ME+-T 2-5.12 USB1 Header • This header is for connecting the additional USB cable to provides you two additional USB ports. User can order the additional USB cable from your mainboard dealer and vender. Additional USB Cable (Optional) Black Black Green Green White...

  • Page 39: Irq Description

    Chapter 2 Hardware Setup 2-6 IRQ Description Function Description Priority IRQ 0 System Timer IRQ 1 Keyboard Controller IRQ 2 Programmable Interrupt IRQ 3 Serial Port (COM 2) IRQ 4 Serial Port (COM 1) IRQ 5 IRQ 6 Floppy Disk Controller IRQ 7 Parallel Port (LPT1) IRQ 8...
  • Page 40 65ME-T/ME+-T MEMO MEMO...

  • Page 41: Chapter 3 Software Setup

    Chapter 3 Software Setup Chapter 3 Software Setup Drivers, Utilities and Software Installation • Support CD: This series of mainboards will always be shipped with a Support CD which contains those necessary driver files, Application Softwares and some helpful utilities. It is a user-friendly, auto-run CD which will open itself up in a CD-ROM automatically.

  • Page 42: Open Up The Support Cd And Choose Drivers And Utilities

    65ME-T/ME+-T 3-1 Open up the Support CD and choose Drivers and Utilities 1 Please put the Support CD enclosed in your mainboard package into the CD-ROM drive. In a few seconds, the Main Menu will automatically appear, displaying the contents to be installed for this series: Intel Chipset Software Installation Utility (INF Utility) Intel Application Accelerator (IAA) Intel 815 Chipset Graphics Driver Installation...

  • Page 43: Install "Intel Chipset Software Installation Utility

    Chapter 3 Software Setup 3-2 Install “Intel Chipset Software Installation Utility” 1 Following the procedures of opening the Support CD, click to “ Install Intel Chipset software installation Utility” to proceed. 2 The Intel Service Pack Install Shield Wizard will pop up to guide you to the Intel Service pack installation.

  • Page 44: Install "Intel Application Accelerator

    65ME-T/ME+-T 3-3 Install “Intel Application Accelerator” IAA supports all Windows 98/98se/Mellennium/NT4/2000/XP with Pentium III / 4 processor. Installations of this software for these operating systems are similarly programed to an auto-run mode, and it is typically designed to improve performance of the storage sub- system and overall system performance.
  • Page 45 Chapter 3 Software Setup 4 On ”Choose Destination Location” screen, press “Yes” to continue. C : \ P r o g r a m F i l e s \ I n t e l \ I n t e l Application Accelerator 5 On ”InstallShield Wizard Com- plete”...

  • Page 46: Install "Intel 815 Chipset Graphics Driver

    65ME-T/ME+-T 3-4 Install “Intel 815 Chipset Graphics Driver” 1 Following the procedures of opening the Support CD, click to “Graphics Driver” to proceed. 2 On the “installshield Wizard” screen, click on “Next” to continue. Next 3 Press “Yes” to accept Software License Agreement.

  • Page 47: Creative Audio Driver Installation (For 65Me+-T Only)

    Chapter 3 Software Setup 3-5 Creative Audio Driver Installation (For 65ME+-T Only) Please open your Support CD with your CD-ROM drive and select “Creative Audio Driver [Optional] “ to proceed. 3-5.1 To Install Creative Audio Driver 1 As soon as you click to the “Cre ative Audio Driver [Optional]”, the “Licence Agreement”...

  • Page 48: 3-5.2 To Enable The Rear Line Out (For 4 Speakers)

    65ME-T/ME+-T 3-5.2 To Enable The Rear Line Out (For 4 Speakers) After Installation Of Creative Audio Drivers, you should enable the Rear Line Out connector for 4-channel speaker. 1 Click to “My computer” icon, and then “Control Panel”, and then “System”, and you will see the “System Properties”...

  • Page 49: 3-5.3 Identifying Connectors On The Built-In Audio

    Chapter 3 Software Setup 3-5.3 Identifying Connectors On The Built-in Audio Intel 82815 GMCH AUXFA1 CD_IN1 CD_IN2 TAD1 JP21 LINE OUT First Speaker Out CD Audio Connector 2 LINE IN Rear LINE OUT CD Audio Connector 1 J A C K ( S e c o n d p a i r o f speakers output for 65ME+-T Telephone Answering Device only)

  • Page 50: Ac'97 Audio Driver Installation (For 65Me-T Only)

    65ME-T/ME+-T 3-6 AC’97 Audio Driver Installation (For 65ME-T Only) Please open the support CD with your CD-ROM and ckick to “ AC’97 Audio Driver [Optional]”. 1 The next screen will appear for user to select which AC’97 driver you need to install. Supposing that your system is one of Windows 98SE/ ME/Win2000, then click on the “Install AC’97 Driver for Win98SE/ ME/Win2000 ”.

  • Page 51: Proceed To Hardware Monitor Utility Installation

    Chapter 3 Software Setup 3-7 Proceed To Hardware Monitor Utility Installation 1 You have to install Hardware Monitor manually. Please click to the following path to execute Hardware Monitor installation: D: \ Hardwaremonitor\ ITE \ Install.exe (assuming that your CD-ROM Drive is Drive D) 2 In case you are already on the Installation Main Menu of the Support CD, please click to the “Install Hardware Monitor”.
  • Page 52 65ME-T/ME+-T 5 To display the Hardware Monitor Utility, just click on the “ITE SMARTGUARDIAM” icon in your program file, and the following screen of Smartguardian Control Panel will show up, displaying the information about system temperatures, voltages and Fan speed. Clicking to the “Option”...
  • Page 53 Chapter 3 Software Setup MEMO MEMO...

  • Page 54: Chapter 4 Bios Setup

    65ME-T/ME+-T Chapter 4 BIOS Setup THE BIOS • BIOS stands for Basic Input and Output System. It is sometimes called ROM BIOS because it is stored in a Read-Only Memory(ROM) chip on the mainboard. BIOS is the first program to run when you turn on your computer.

  • Page 55: What Is Bios Setup

    Chapter 4 BIOS Setup 4-1 What Is BIOS Setup • BIOS setup is an interactive BIOS program that you need to run when: 1. Changing the hardware of your system. (For example: installing a new Hard Disk etc.) 2. Modifying the behavior of your computer. (For example: changing the system time or date, or turning special features on or off etc.) 3.

  • Page 56: 4-5.1 Before Upgrading Bios

    65ME-T/ME+-T • The upgrade utility can be loaded on a floppy diskette and used to provide the capability to save, verify, and update the system BIOS. The upgrade utility can be run from a hard disk drive or a network drive. 4-5.1 Before Upgrading BIOS •...
  • Page 57 Chapter 4 BIOS Setup Step 4. Type awdflash *.bin /sn/py/cc and then press <Enter> to run BIOS upgrade program. (*.bin depends on your mainboard model and version code. Instead of typing “*”, you should type specific file name for your specific mainboard). Step 5.
  • Page 58 65ME-T/ME+-T Award Flash Memory Writer Start Screen Award Flash Memory Writer Complete Screen...
  • Page 59 Chapter 4 BIOS Setup The parameters of AWDFLASH.EXE /sn: No original BIOS backup /py: Program flash memory /cc: Clear CMOS data (and update data automatically) after programming NOTE: Users can type AWDFLASH /? to get further details about the parameters. Incorrect usage of the parameter will damage the BIOS information, so we strongly recommend user to leave parameters alone unless you fully understand their function.

  • Page 60: Bios Setup

    65ME-T/ME+-T 4-6 BIOS Setup --- CMOS Setup Utility 4-6.1 CMOS Setup Utility • This mainboard comes with the AWARD BIOS from AWARD Software Inc. Enter the CMOS Setup Utility Main Menu by: 1. Turn on or reboot your system. After a series of diagnostic checks, the following message will appear: PRESS <DEL>...

  • Page 61: 4-6.2 Standard Cmos Setup

    Chapter 4 BIOS Setup 4-6.2 STANDARD CMOS SETUP • Standard CMOS Setup records some basic system hardware configuration and sets the system clock and error handling. You only need to modify the configuration values of this option if you want to change your system hardware configuration or when the data stored in the CMOS memory gets lost or damaged.
  • Page 62 65ME-T/ME+-T Date (mm:dd:yy) The BIOS determines the day of the week from the other date information. This field is for information only. Press the left or right arrow key to move to the desired field (date, month, year). Press the PgUp or PgDn key to increment the setting, or type the desired value into the field.
  • Page 63 Chapter 4 BIOS Setup Drive A / Drive B Select this field to the type(s) of floppy disk drive(s) installed in your system. The choices are: 360KB, 5.25in; 1.2MB, 5.25in; 720KB, 3.5in; 1.44MB, 3.5in; 2.88MB, 3.5in; None. Video Select the type of primary video subsystem in your computer.

  • Page 64: 4-6.3 Advanced Bios Features

    65ME-T/ME+-T 4-6.3 Advanced BIOS Features • Advanced BIOS Features improves your system performance or sets up system features according to your preference. Run the Advanced BIOS Features as follows: 1. Choose “Advanced BIOS Features” from the Main Menu and a screen with a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Advanced BIOS Features...
  • Page 65 Chapter 4 BIOS Setup 2. Use one of the arrow keys to move between options and modify the selected options by using PgUp / PgDn / + / - keys. An explanation of the <F> keys follows: <F1>: “Help” gives options available for each item. <F5>: Get the previous values.
  • Page 66 65ME-T/ME+-T Processor Number Choose Disabled or Enabled. When enabled, the Feature processor serial number will display during the boot up screen. Quick Power On Self Select Enabled to reduce the amount of time required to Test run the power-on self-test (POST). A quick POST skips certain steps.
  • Page 67 Chapter 4 BIOS Setup Typematic Rate Setting When Disabled, the following two items (Typematic Rate and Typematic Delay) are irrelevant. Keystroke repeats at a rate determined by the keyboard controller in your system. When Enabled, you can select a typematic rate and typematic delay.

  • Page 68: 4-6.4 Advanced Chipset Features

    65ME-T/ME+-T 4-6.4 Advanced Chipset Features • Advanced Chipset Features is used to modify the values of chipset buffers. These buffers control the system options. Run the Advanced Chipset Features as follows: 1. Choose “AAdvanced Chipset Features” from the Main Menu and a list of option will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Advanced Chipset Features...
  • Page 69 Chapter 4 BIOS Setup SDRAM CAS Latency When synchronous DRAM is installed, the number Time of clock cycles of CAS latency depends on the DRAM timing. Do not reset this field from the default value specified by the system designer. SDRAM Cycle Time Select the number of SCLKs for an access cycle.
  • Page 70 65ME-T/ME+-T CPU Latency Timer Use Default setting. Delayed Transaction The chipset has an embedded 32-bit posted write buffer to support delay transactions cycles. Select Enabled to support compliance with PCI specification version 2.1. AGP Graphics Aper- Choose 32, 64 MB. Memory mapped and graphics ture Size data structures can reside in a Graphics Aperture.

  • Page 71: 4-6.5 Integrated Peripherals

    Chapter 4 BIOS Setup 4-6.5 Integrated Peripherals • Integrated Peripherals option allows you to get some information inside your system when it is working. Run the Integrated Peripherals as follows: 1. Choose “Integrated Peripherals” from the Main Menu and a list of options will appear: 2.
  • Page 72 65ME-T/ME+-T CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Integrated Peripherals On-Chip Primary PCI IDE Item Help Enabled On-Chip Secondary PCI IDE Enabled Menu Level IDE Primary Master PIO Auto IDE Primary Slave PIO Auto IDE Secondary Master PIO Auto IDE Secondary Slave PIO Auto...
  • Page 73 Chapter 4 BIOS Setup On-Chip Primary/ The chipset contains a PCI IDE interface with support Secondary PCI IDE from two IDE channels. Select Enabled to activate the first and/or the second IDE interface. Select Disabled to deactivate an interface if you install a primary and/or second add-on IDE interface.
  • Page 74 65ME-T/ME+-T Onboard/CNR LAN Use the default setting. Selection The choices: Auto; Onboard IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read/write. If your IDE hard drive supports block mode (most new drives do), select Enabled for automatic detection of the optimal number of block read/write per sector the drive can support.
  • Page 75 Chapter 4 BIOS Setup UART Mode Select The second serial port on your system may offer a variety of infrared port modes. Click here for a description of various modes. (Click your browser ’s Back button, or your right mouse button, to return to this page.) The choices: Standard;...

  • Page 76: 4-6.6 Power Management Setup

    65ME-T/ME+-T 4-6.6 Power Management Setup • Power Management Setup allows you to set the system’s power saving functions. Run the Power Management Setup as follows: 1. Choose “Power Management Setup” from the Main Menu and a list of options will appear: CMOS Setup Utility - Copyright (C) 1984 - 2001 Award Software Power Management Setup ACPI Function...
  • Page 77 Chapter 4 BIOS Setup 2. Use one of the arrow keys to move between options and modify the selected options by using PgUp / PgDn / + / - keys. An explanation of the <F> keys follows: <F1>: “Help” gives options available for each item. <F5>: Get the previous values.
  • Page 78 65ME-T/ME+-T Video Off Method This determines the manner by which the monitor is blanked. This selection will cause the system to turn off the vertical and horizontal synchronization ports and write blanks to the V/H SYNC + Blank video buffer. Blank Screen This option only writes blanks to the video buffer.
  • Page 79 Chapter 4 BIOS Setup Wake-up by PCI card This function allows you to enabled the system by wake-up by PCI card. The choices: Delay 4 Sec; Instant-Off. Power On by Ring An input signal on the serial Ring Indicator (RI) line (in other words, an incoming call on the modem) awakens the system from a soft off state.
  • Page 80 65ME-T/ME+-T Reload Global Timer Reload Global Timer Events are I/O events whose Events occurrence can prevent the system from entering a power saving mode or can awaken the system from such a mode. In effect, the system remains alert for anything which occurs to a device which is configured as Enabled, even when the system is in a power down mode.

  • Page 81: 4-6.7 Pnp / Pci Configuration

    Chapter 4 BIOS Setup 4-6.7 PNP / PCI Configuration • PNP / PCI Configuration allows you to modify the system’s power saving functions. Run the PNP / PCI Configuration as follows: 1. Choose “PNP / PCI Configuration” from the Main Menu and a screen with a list of options will appear: CMOS Setup Utility - Copyright (C) 1984 - 2001 Award Software PnP/PCI Configurations...
  • Page 82 65ME-T/ME+-T Reset Configuration Normally, you leave this Disabled. Select Enabled Data to reset Extended System Configuration Data (ESCD), when you exit Setup if you have installed a new add-on and the system reconfiguration has caused such a serious conflict that the operating system cannot boot.
  • Page 83 Chapter 4 BIOS Setup PCI SLOT1/5, 2, 3, 4 These options allow you to assign an IRQ for each IRQ Assigned PCI SLOT and this is a useful function when you want to clear the IRQ conflict for a specific device. The options are available : Auto;...

  • Page 84: 4-6.8 Pc Health Status

    65ME-T/ME+-T 4-6.8 PC Health Status • This section helps you to get more information about your system including CPU temperature, FAN speed and voltage. It is recommended that you contact your mainboard supplier to get proper values about the setting of the CPU temperature. Run the “PC Health Status”...
  • Page 85 Chapter 4 BIOS Setup Shutdown Tempera- This feature prevents your CPU from damage by ture over heat. If the CPU’s temperature is higher than “CPU warning temperature” that you select in this field, the BIOS will shut down your system within 3 seconds.

  • Page 86: 4-6.9 Frequency/Voltage Control

    65ME-T/ME+-T 4-6.9 Frequency/Voltage Control Run the “Frequency/Voltage Control” as follows: 1. Choose “Frequency/Voltage Control” from the Main Menu and a screen with a list of options will appear: CMOS Setup Utility - Copyright (C) 1984-2001 Award Software Frequency Control Item Help Redstorm Overclocking Tech Press Enter Auto Detect DIMM/PCI Clk...
  • Page 87 Chapter 4 BIOS Setup Redstorm Please press <Enter> to start RED STORM OVER- Overclocking CLOCKING TECH, this option helps user an easy Tech way to overclocking, it will increase CPU external clock automatically, when CPU external clock in- creasing to unacceptable value, BIOS will restart your system, then running at acceptable CPU ex- ternal clock.
  • Page 88 65ME-T/ME+-T SDRAM Skew This item allows you to reduce SDRAM transfer rate. Adjust Users should leave this item at default value. The choices: Disabled; 150ps; 300ps; 450ps. AGP Skew This item allows you to reduce AGP transfer rate. Adjust Users should leave this item at default value. The choices: Disabled;...

  • Page 89: 4-6.10 Load Optimized Defaults

    Chapter 4 BIOS Setup 4-6.10 Load Optimized Defaults • When you press <Enter> on this item, you will get a confirmation dialog box with a message similar to: “ Load Optimized Defaults (Y/N) ? N ” “Y” is for “Yes”, and “N” is for “No”. Pressing “Y”...

  • Page 90: 4-6.12 Save & Exit Setup

    65ME-T/ME+-T 7. Move the cursor to Save & Exit Setup to save the option you have just configured; otherwise the old password will still be there the next time you turn your system on. 8. Press <Enter> to exit to the Main Menu. NOTE: If you forget or lose the password, the only way to access the system is to clear the CMOS RAM.
  • Page 91 Chapter 4 BIOS Setup MEMO MEMO...

  • Page 92: Appendix

    65ME-T/ME+-T Appendix Appendix-1 Identifying BIOS Version/BIOS Part Number Appendix-2 Identifying Mainboard Model Number Appendix-3 Technical Terms...

  • Page 93: Appendix-1 Identifying Bios Version & Bios Part Number

    APPENDICES Appendix-1 Identifying BIOS Version & BIOS Part Number • See Picture-2 below for BIOS version and BIOS part number identification. Picture-2 BIOS VERSION example: REV T2.1 BIOS ID STRING example: 6A69RSNCC...

  • Page 94: Appendix-2 Identifying Mainboard Model Number

    65ME-T/ME+-T Appendix-2 Identifying Mainboard model Number • Usually the mainboard model number is labeled on the side of ISA side of slot or PCI slot. Please see the picture below as an illustration: MAINBOARD MODEL NUMBER example: SL-65KV2 MAINBOARD SERIAL NUMBER example: 0012000T005679...

  • Page 95: Appendix-3 Technical Terms

    APPENDICES Appendix-3 Technical Terms AC’97 AC’97 is a device designed to include a digital processor for modem and an audio CODEC for analog I/O. These two parts are linked together by AC’97 link bus. Putting the digital processor into the main system chipset will reduce the cost of sound/modem onboard solution.
  • Page 96 65ME-T/ME+-T ATAPI (AT Attachment Packet Interface) This is the exension of the EIDE (extended IDE) that enables the interface to support CD-ROM players and tape drives. BIOS (Basic Input/Output System) BIOS is a set of assembly routine/program that resides in EPROM or Flash ROM.
  • Page 97 APPENDICES DIMM (Dual In Line Memory Module) DIMM socket is built with a 168-pin assignment and supports 64-bit data. DIMM can be single or double sided. The golden finger signals on each side of the module are different, and that is why it is called Dual In Line. Almost all DIMMs are made with SDRAM now, which operate at 3.3V.
  • Page 98 65ME-T/ME+-T FC-PGA (Flip Chip-Pin Grid Array) FC means Flip Chip, while FC-PGA is a new package of Intel for Pentium III CPU. It is compatible with SKT370 socket, but requires mainboard to add some signals on socket 370. Flash ROM Flash ROM can be re-programmed by electronic signals.
  • Page 99 APPENDICES PC-1600 or PC-2100 DDR SDRAM PC-1600 DDR SDRAM with a 64-bit data bus doubles the data transfer rate of PC100 SDRAM and hence provides data transfer bandwidth up to 100x64/ 8x2=1600MB/s. PC2100 DDR SDRAM doubles the data transfer rate of PC-133 and hence provides data transfer bandwidth up to 133x64/ 8x2=2100MB/s.
  • Page 100 65ME-T/ME+-T SDRAM (Synchronous DRAM) SDRAM is one of the Dynamic Random Access Memory (DRAM) technologies that allow DRAM to use the same clock as the CPU host clock (EDO and FPM are asynchronous and do not have clock signal). SDRAM comes in 64-bit 168-pin DIMM and operates at 3.3V.
  • Page 101 APPENDICES USB (Universal Serial Bus) USB is a 4-pin serial peripheral bus that is capable of cascading low/medium speed peripherals (less than 10Mbit/s) such as keyboard, mouse, joystick, scanner, printer and modem. VCM (Virtual Channel Memory) NEC’s Virtual Channel Memory (VCM) is a new DRAM core architecture that dramatically improves the memory system’s ability to service multimedia requirements.
  • Page 102 65ME-T/ME+-T MEMO MEMO...
