SOLTEK NF4-754RL Manual page 51

SL-NF4-754RL
IDE Function Setup:
To press< Enter > on IDE Function Setup will reveal the following items.
OnChip IDE Channel0
Primary Master PIO
Primary Slave PIO
Primary Master UDMA
Primary Slave UDMA
OnChip IDE Channel1
Secondary Master PIO
Secondary Slave PIO
Secondary Master UDMA
Secondary Slave UDMA
IDE DMA transfer access
Serial-ATA 1
Serial-ATA 2
IDE Prefetch Mode
On-Chip IDE Channel
Master / Slave PIO
Secondary
Master / Slave PIO
Master / Slave UDMA
Secondary
Master / Slave UDMA
IDE DMA Transfer
Serial-ATA1/2 To enable / disable the Serial-ATA interface 1/2.
IDE Prefetch Mode The on-board IDE drive supports IDE prefetching
Phoenix - AwardBIOS CMOS Setup Utility
IDE Function Setup
To enable / disable the Primary / Secondary IDE
0/1 channel.
The choices: Enabled; Disabled
Primary
Choose Auto or Mode 0~4. The BIOS will detect the
HDD mode type automatically when you choose
Auto. You need to set to a lower mode than Auto
when your hard disk becomes unstable.
The choices: Auto; Mode 0; Mode 1; Mode 2;
Primary Ultra DMA33/66/100/133 implementation is possible
only if your IDE hard drive supports it, if the operat-
ing environment includes a DMA drive, and if your
system software supports Ultra DMA33/66/100/133.
Select "Auto" to enable BIOS support.
The choices: Auto; Disabled
To enable / disable the IDE DMA transfer access.
Access The choices: Enabled; Disabled
Choices: Enabled; Disabled
for faster drive accesses. If the IDE device doesn't
support prefetching, set this field to Disabled.
The choices: Enabled; Disabled
Enabled
Auto
Auto
Auto
Auto
Enabled
Auto
Auto
Auto
Auto
Enabled
Enabled
Enabled
Enabled
Mode 3; Mode 4
54
Chapter 4 BIOS Setup
Item Help
