Connectors
Table 2-10. OmniVision Connector Pinout (J2) (Cont'd)
Pin #
24,23,26,25
28,27,30,29

LCD Connector Pinout

Table 2-11. LCD Connector Pin-out (P8)
Pin #
1,5,6,12,19,20,26
2
3
4
7,8,9,10,11
13,14,15,16,17,18
21,22,23,24,25
27
28,29
30
31
32
2-12
Mnemonics Name
UV3–UV0 UV data bit 3–0
UV7–UV0 UV data bit 7–4
Mnemonics
GND
PPICLK
FSYNC1
FSYNC2
D4–D0
D10–D5
D15–D10
3.3V
INV-SC
THERM1
THERM2
ADSP-BF53x Processor
PPI [11–8]
PPI [7–4]
Signal Name ADSP-BF53x Processor
Ground
PPI Clock PPI Clock
Frame Sync 1 See
Frame Sync 2 See
Data bit 4–0 PPI [4–0]
Data bit 10–5 PPI [10–5]
Data bit 15–11 PPI [15–11]
10k pull-down to
GND
3.3V Power
Invert Screen
Thermistor 1
Thermistor 2
ADSP-BF53x EZ-Extender 1 Manual
Table 2-4 on page 2-8.
Table 2-5 on page 2-8.
