4-6.9 CPU Ratio/Voltage Control

Run the "CPU Ratio/Voltage Control" as following:
Choose "CPU Ratio/Voltage Control" from the Main Menu and a screen
with a list of options will appear:
CPU Clock Ratio
Auto Detect PCI Clk
Spread Spectrum
Async AGP/PCI CLK
CPU Clock
AGP Voltage Select
DIMM Voltage Select
: Move Enter: Select
F5: Previous Values
CPU Clock
Auto Detect PCI
Spread Spec-
Async AGP/PCI
CPU Clock This items allows users to adjust CPU frequency.
AGP Voltage
DIMM Voltage
Phoenix - AwardBIOS CMOS Setup Utility
CPU Ratio/Voltage Control
+/-/PU/PD: Value F10: Save
F6: Fail-Safe Defaults
If CPU onboard is one with an adjustable or un-
Ratio locked CPU ratio, this item allows you user to ad-
just the CPU Ratio. If your CPU is one with the
CPU Ratio locked, this item will be invalid.
To enable / disable the Auto-detect PCI clock
CLK function.
When the system clock generator pulses, the ex-
trum treme values of the pulse generate excess EMI.
Enabling pulse spectrum spread modulation
changes the extreme values from spikes to flat
curves, thus reducing EMI.
Toset the Asynchronous AGP/PCI clock.
Clk Choices: Disabled; 66/33MHz; 80/40MHz;73/36Mhz
Choices: 133-165Mhz
Allows you to configure the AGP Voltage.
Select Choices: 1.5V; 1.6V; 1.7V; 1.8V
Allows you to configure the DIMM Voltage.
Select Choices: 2.6V; 2.7V; 2.8V
10X
Enabled
Disabled
Disabled
133MHz
1.5V
2.6V
