Replacing the Printhead
Important
3
Pull the Printhead Fixer Lever forward all the way to open it
completely.
4
Pull up the Printhead Fixer Cover to open it completely.
5
Remove the Printhead and press the OK button.
506
Important
Note
• Do not touch the Linear Scale (a) or Carriage Shaft
(b). Touching these parts may damage them.
•
Never touch the metal contacts of the Carriage. Furthermore, do not allow any dirt or debris to become
adhered to the metal contacts of the Carriage. These may damage the printer.
•
Dispose of the used Printhead in accordance with local regulations.
iPF770
b a
