Printing Line Drawings and Text (Mac OS)

6
Click the Page Setup tab to display the Page Setup
sheet.
7
A
In Page Size, click the size of the original as specified in the application. In this case, click ISO A3.
8
Select and click a roll paper in the
9
Select the width of the loaded roll in the
(420.0mm).
10
Specify additional printing conditions.
For details on available printing conditions, see "Printer Driver Settings ."
11
Confirm the print settings and print as desired.
Note

Printing Line Drawings and Text (Mac OS)

Printing Line Drawings and Text (Mac OS)
This topic describes how to print line drawings based on the following example.
Document: CAD drawing
•
• Page size: A3 (297.0 × 420.0 mm [11.7 × 16.5 in])
• Paper: Roll
• Paper type: Plain Paper
• Roll paper width: A2/A3 roll (420.0 mm [16.5 in])
1
Choose Page Setup from the application menu to
display the Page Attributes dialog box.
40
L
•
For tips on confirming print settings, see "Confirming Print Settings ."
Paper Source list.
M
Roll Paper Width list—in this case, ISO A2/A3 Roll
P.140
➔
P.143
➔
