INSTALLATION — WIRING
CAUTION: Before you begin wiring/connecting your system, read
Instructions'
starting on page 4.
WIRING PARTS
YOU WILL NEED:
1 × TVMS Rogue (TVMS1240 — includes TVMSWK-001 Wiring Kit)
ƒ
50 A Midi fuse with fuse holder — REDARC FK50 recommended
ƒ
Tools and consumables as needed (see below)
ƒ
If your install includes a REDARC Manager, you will also need:
40 A Midi fuse with fuse holder — REDARC FK40 recommended
ƒ
TOOLS
The tools listed may be required for mounting and wiring the TVMS Rogue:
Screwdriver set
ƒ
Spanner set
ƒ
Pliers
ƒ
Side/Cable cutters
ƒ
CONSUMABLES
Components not included with the TVMS Rogue may be required for wiring connections and cable
management, including:
Cable/Wire
ƒ
Cable connectors e.g. Butt-splices
ƒ
Lugs / Ring terminals
ƒ
Electrical tape
ƒ
CAUTION
Selecting the wrong cable or fuse size could result in harm to the installer or user and/or
ƒ
damage to the battery or other equipment installed in the system. The installer is responsible
for ensuring that the correct cable type and fuse sizes are used when installing the
TVMS Rogue.
Wiring must be installed in protected areas away from heat sources and sharp objects. Cables
ƒ
must not be routed over or through moving parts of the vehicle. Additional protection such as
conduit may be required, especially if routing cables through the engine bay.
'Warnings and Safety
Ratcheting or Hydraulic crimping tool
ƒ
Heat gun
ƒ
Soldering Iron
ƒ
Heat Shrink
ƒ
Cable ties
ƒ
Conduit / Split tubing
ƒ
Fasteners / P-Clips
ƒ
Installation — Wiring | 17
