INSTALLATION — WIRING
IMPORTANT: Before you begin wiring and connecting any part of the TVMS Rogue, read ALL information listed in 'Warnings and
Safety Instructions' on page 4.
ORDER OF CONNECTIONS
Ensure all Input and Output connections are correctly wired before connecting the Power Input Connector wiring to the 12 V auxiliary battery.
CAN BUS CONNECTION (B)
Connecting the TVMS Rogue the RedVision system.
NOTICE: Do NOT connect computers or IT equipment to R-Bus Network (B) on the TVMS Rogue. This may damage the Main Unit
internal components.
Connect as shown in 'Wiring Diagram — Basic Install' (page 5).
OUTPUT WIRING (C/D)
Connecting the TVMS Rogue outputs to 12 V loads.
Read the following important safety instructions (page 4): 20, 25, 27, 28, 29,
SENSOR INPUT WIRING (E A1–A2)
Connecting the TVMS Rogue to analogue sensors.
Read the following important safety instructions (page 4): 25,
