SYSTEM EXAMPLE

Every Output, Sensor and Switch
is fully configurable for total
customisation for your setup.
Assign unique icons, names and
behaviours for every device so you
can easily monitor and control the
system when you're on the road.
Here is an example configuration for
a caravan/travel trailer.
Outputs 10 × 10A
Living Room Light
Bedroom Light
Awning Light
Flood Light
Water Pump
Inverter (signal only)
USB and Acc Sockets
Fridge
2
Stereo
1
Fans and TV
Switch Inputs
Light Switches
Water Pump Switch
Ignition Signal
Sensor Inputs
Tank Level Sensor 1
Tank Level Sensor 2
Free REDARC
Configurator App
Display and
smartphone not
included.
Overview | 7
