Part 3.2: Gigabit Ethernet Interface

The AX7201 FPGA carrier board provides users with 4-channel Gigabit
network communication service through the Realtek RTL8211EG Ethernet
PHY chip. The RTL8211EG chip supports 10/100/1000 Mbps network
transmission rate and communicates with the FPGA through the GMII interface.
RTL8211EG supports MDI/MDX adaptive, various speed adaptations,
Master/Slave adaptation, and support for MDIO bus for PHY register
management.
The RTL8211EG will detect the level status of some specific IOs to
determine their working mode after powered on. Table 3-1-1 describes the
default setup information after the GPHY chip is powered on.
Configuration Pin
PHYAD[2:0]
SELRGV
AN[1:0]
RX Delay
TX Delay
Mode
When the network is connected to Gigabit Ethernet, the data
transmission of FPGA and PHY chip RTL8211EG is communicated through the
GMII bus, the transmission clock is 125Mhz. The receive clock E_RXC is
provided by the PHY chip, the transmit clock E_GTXC is provided by the FPGA,
and the data is sampled on the rising edge of the clock.
When the network is connected to 100M Ethernet, the data transmission of
FPGA and PHY chip RTL8211EG is communicated through the GMII bus, the
transmission clock is 25Mhz. The receive clock E_RXC is provided by the PHY
chip, the transmit clock E_GTXC is provided by the FPGA, and the data is
www.alinx.com
ARTIX-7 FPGA Development Board AX7201 User Manual
Instructions
MDIO/MDC Mode PHY Address
3.3V, 2.5V, 1.5/1.8V voltage
selection
Auto-negotiation configuration
RX clock 2ns delay
TX clock 2ns delay
RGMII or GMII selection
Table 3-2-1: PHY chip default configuration value
Configuration value
PHY Address 011
3.3V
(10/100/1000M) adaptive
Delay
Delay
GMII
