Dynamic zeroing and
stabilizing time
Maximum sampling
time
Cont.ZERO Failure
Alarm Threshold
Number of Averaging
Samples
Plus frequency
Skip Samples
Diff in Gram
Target Weight
Tendency Max.Limit
Tendency Min.Limit
Servo motor dead zone If the absolute value of weight error is lower than this value, it
Maximun servo
modulation
Tendency Max.Limit
Alarm&Stop
Tendency Min.Limit
Alarm&Stop
this setting value, and only when it is stable can dynamic
zeroing be allowed
When the belt is running, within this setting value, the range of
weight variation is judged as the stability of the scale platform
within the range of dynamic zero clearance stability. Only when
the stability allows the dynamic zero clearance
Maximum sampling time during weighing
How many times did the weighing platform fail to reset
dynamically during the weighing process
During servo control, the average value of the set number of
products is compared with the user set value, and the
difference between them is used as the basis of control. When
it is 0, the filling servo function is not used
Pulse frequency value of servo motor
It is equivalent to the number of objects from the charging
machine to the photoelectric switch of the weighing scale. It
also refers to the number of products passed before the next
correction
This setting is the adjusted weight corresponding to each
correction pulse
Equivalent to the target value of package inspection weight
When the weight is higher than this value, it will not participate
in the average value calculation and will generate an alarm
When the weight is lower than this value, it will not participate
in the average value calculation and will generate an alarm
will not be corrected
Refers to the maximum allowable modulation correction
Eliminate servo upper limit alarm shutdown
Eliminate servo lower limit alarm shutdown
