VCX V7111 Front Panel LEDs

Definition of VCX V7111 Front Panel LED Indicators
Table 12
LED Type
Ready Device
Status
LAN Ethernet
Link Status
Control Control
Link
Data Packet
Status
Channels Telephone
Interface
VCX V7111 Fast Track Installation Guide
ONITORING THE
Color State
Green ON
Orange Blinking
Red ON
Green ON
Red ON
Green Blinking
Red ON
Orange ON
Green Blinking
Red Blinking
Blank
Green ON
Green Blinking
Red ON
Blank -
VCX V7111
Definition
Device powered, self-test OK
Software loading/Initialization
Malfunction
Valid 10/100 Base-T Ethernet connection
Malfunction
Activity, when control messages sent/received
in real time
No registration with Call Agent, no response
from Call Agent/ Gatekeeper
No RT messages with Call Agent, but Call
Agent is responding
Transmitting packets
VCX V7111 is receiving data packets
No traffic
The phone is off-hooked (FXS); the FXO off-
hooks the line towards the PBX.
There's an incoming call, before answering
Line malfunction
Normal on-hook position
