VCX V7111 Rear Panel LEDs

Definition of VCX V7111 Rear Panel LED Indicators
Table 14
Label Type
ETH-1 Ethernet
Status
Ethernet LEDs are located within the RJ-45 socket.
VCX V7111 Fast Track Installation Guide
Color State Definition
Yellow ON Ethernet port receiving data
Red ON Collision
