C 5: 4FXO: IP
HAPTER
PBX E
XAMPLE

Analog Line Interconnect Through the IP Network

Figure 22 shows an example of the 4FXO mediating between the PBX/PSTN world and the
IP network. A is an enterprise in Europe with its own PBX and the 4FXO connected to analog
lines. B is a SOHO (Small Office, Home Office) in the USA, without a PBX, but with the
4FXS connected to the phones.
A calling B scenario (One-stage dialing set in the INI File)
User A off-hooks the phone, hears the 3Com VCX dial tone, and dials User B's phone
1
number 4133.
The call is routed to the analog line connected to the 4FXO which routes it to the 4FXS
2
that maps it to the phone of User B.
B calling A scenario (One-stage dialing set in the INI File)
User B off-hooks the phone, hears the 4FXS device's dial tone, and dials 4247.
1
The 4FXS device routes the call to the 4FXO which dials it to the 3Com VCX, which
2
routes it to User A's extension.
VCX V7111 Fast Track Installation Guide
E
TO NTERPRISE
41
