8 INTELLIGENT SYSTEM
PROTECTION (ISP)
ISP (Intelligent System Protection) was developed by LOGICDATA to reduce the risk of pinching when a
moving table hits an obstacle. A load change can be detected, either by sensors in the actuators, or other
sensors. The table will stop instantly and move in the opposite direction for a few millimeters.
There are two types of ISP:
Software ISP
Software ISP uses known system variables that are measured or calculated by each controlbox. Additional
sensors are not necessary, this function is available with all LOGICDATA controlboxes and all drives.
Sensor ISP
Optionally, the drive can be equipped with sensor ISP, which increases the sensitivity of the collision detection.
NOTICE
The description of the activation and deactivation of ISP sensors can be found in the
corresponding manual of the controlbox.
NOTICE
The ISP sensitivity and the ISP switch-off value depend on the complete system
(mechanical and electronic components). To determine the ISP suitability of a height-
adjustable table, please contact LOGICDATA!
NOTICE
Within a system, drives with and without ISP sensors cannot be mixed. Each drive
must be of the same type.

9 DISASSEMBLY

For disassembly, disconnect the DCDinline D from the power supply and proceed in reverse order to assembly.
