Summary of Contents for LOGICDATA OPTIMUS Frame

  • Page 2 OPTIMUS FRAME ORIGINAL USER MANUAL // PAGE 2 OPTIMUS Frame - Original User Manual Document Version 2.0 / July 2023 This document was originally published in English LOGICDATA Electronic & Software Entwicklungs GmbH Wirtschaftspark 18 8530 Deutschlandsberg Austria Telefon: +43 (0) 3462 51 98 0...

  • Page 3: Table Of Contents

    OPTIMUS FRAME ORIGINAL USER MANUAL // PAGE 3 CONTENTS Introduction and General Product Information Introduction Intended Use Reasonably Foreseeable Misuse Important Information Safety Instructions (Warnings) OPTIMUS Frame Description Technical Data Assembly Instructions Operation Information Perform an End Position Reset Operation of the OPTIMUS Frame 7.2.1 Basic Handset and Basic Handset with Display...

  • Page 4: Introduction And General Product Information

    This User Manual is intended for the manufacturer of the equipment or system (OEM), and serves as a resource for the installation, operation, and maintenance the LOGICDATA frame system it depicts. It is important that manufacturers of the end-user product ensure that any relevant safety information in this...

  • Page 5: Intended Use

    Documentation may include the representation of registered trademarks of goods or services, as well as information about copyright or other proprietary expertise of LOGICDATA or third parties. In all cases, all rights remain exclusively with the respective copyright holder. LOGICDATA® is a registered trademark of LOGICDATA Electronic &...

  • Page 6: Safety Instructions (Warnings)

    OPTIMUS FRAME ORIGINAL USER MANUAL // PAGE 6 3 SAFETY INSTRUCTIONS (WARNINGS) Read all instructions before using this product. DANGER To reduce the risk of electric shock Always unplug this furnishing from the electrical outlet before cleaning or servicing. WARNING...
  • Page 7 OPTIMUS FRAME ORIGINAL USER MANUAL // PAGE 7 WARNING Risk of injury through operating damaged products If the system is damaged, it may no longer be safe to use. Continuing to operate damaged products entails a risk of injury. Caution must be exercised to avoid system damage, especially to cables.

  • Page 8: Optimus Frame Description

    OPTIMUS FRAME ORIGINAL USER MANUAL // PAGE 8 4 OPTIMUS FRAME DESCRIPTION The OPTIMUS Frame is a versatile, high-quality table frame designed for the needs of OEMs. With outstanding technology and design, you can use it as the base to create ergonomic systems that meet your needs exactly.

  • Page 9: Technical Data

    OPTIMUS FRAME ORIGINAL USER MANUAL // PAGE 9 5 TECHNICAL DATA Lifting capacity (of the frame, Up to 120 kg (evenly loaded) without tabletop) Product weight ≤ 28,50 kg Adjustment range (without tabletop) 623 mm (± 5 mm) – 1283 mm (± 5 mm)

  • Page 10: Assembly Instructions

    Make sure that the frame is even. Use the levelers on each foot to make any necessary adjustments. For complete assembly instructions, refer to “OPTIMUS Frame Assembly Instructions”. 7 OPERATION INFORMATION PERFORM AN END POSITION RESET Once assembly is complete, you will need to perform an end position reset in order to use the table.

  • Page 11: Basic Handset And Basic Handset With Display

    OPTIMUS FRAME ORIGINAL USER MANUAL // PAGE 11 7.2.1 BASIC HANDSET AND BASIC HANDSET WITH DISPLAY Basic handsets consist of the following elements: UP key DOWN key Fig. 2: Example of Basic Handset 7.2.2 COMFORT HANDSET Comfort handsets consist of 5 key elements:...

  • Page 12: Adjust The Table Top Height

    OPTIMUS FRAME ORIGINAL USER MANUAL // PAGE 12 7.3 ADJUST THE TABLE TOP HEIGHT 7.3.1 TO MOVE THE TABLETOP UP Press and hold the UP key until the desired height has been reached. 7.3.2 TO MOVE THE TABLETOP DOWN Press and hold the DOWN key until the desired height has been reached.

  • Page 13: Troubleshooting And Service

    OPTIMUS FRAME ORIGINAL USER MANUAL // PAGE 13 8 TROUBLESHOOTING AND SERVICE CLICK CODES The control box in your table system uses “clicks” to inform you about the system status and the reason for the last shutdown. Possible signals are as follows:...
  • Page 14 OPTIMUS FRAME ORIGINAL USER MANUAL // PAGE 14 CODE REQUIRED ACTIONS Disconnect the control box from the power. Contact the manufacturer for further information. Disconnect the control box from the power. Ensure all cables are connected correctly. Reconnect the system, then operate as normal.

  • Page 15: Maintenance And Cleaning Information

    OPTIMUS FRAME ORIGINAL USER MANUAL // PAGE 15 9 MAINTENANCE AND CLEANING INFORMATION MAINTENANCE These maintenance instructions are intended for both professional cleaners and end users of the height- adjustable table. Do not use any aggressive substances such as gasoline, acetone, turpentine, petrol, or any solvents or abrasive cleansers.
  • Page 18 LOGICDATA LOGICDATA North America, Inc. Electronic & Software Entwicklungs GmbH 13617 Woodlawn Hills Dr. Wirtschaftspark 18 Cedar Springs, MI 49319 8530 Deutschlandsberg Austria Phone: +43 (0)3462 5198 0 Phone: +1 (616) 328 8841 Fax: +43 (0)3462 5198 1030 E-mail: office.na@logicdata.net E-mail: office.at@logicdata.net...
