6.5 FLANGE SIDE INTERFACE

The figure below provides an overview of the components required to assemble the drive on the flange end.
Fig. 10: Overview of the flange end
1 Mounting screw (adapted by the customer to bottom plate)
2 Bottom plate (developed by the customer, design specifications of LOGICDATA)
3 Flange adjustment point
NOTICE
The design specifications for the bottom plate are available from LOGICDATA only
on request. These includes dimensions and tolerances as well as notes on material
selection and assembly.
CAUTION Danger due to insecure connection
To ensure a secure connection, the top plate must be designed exactly to the
specifications of LOGICDATA. Otherwise, the warranty claims are void.
7 SOFTWARE-DEPENDENT
FUNCTIONS
NOTICE
The description of the software-dependent functions, for example: manual reset, plug
detection or auto detect number of drives can be found in the corresponding manual
of the controlbox.
DCDINLINE D MANUAL // PAGE 17
