5 UNPACKING

The DCDinline D actuator is packaged in a carton.
NOTICE
Ensure proper ESD handling during unpacking. Errors that can be attributed to
electrostatic discharge will void warranty claims
To unpack, proceed as follows:
1. Remove the packaging material from the drive components.
2. Check the contents of the package for completeness and damage.
3. Provide the operating manual to the operating personnel.
4. Dispose of the packaging material.
NOTICE
Dispose of the packaging material in an environmentally friendly manner (separate
the plastic parts and the cardboard by type).

6 ASSEMBLY

6.1

GENERAL ASSEMBLY

NOTICE
Before assembly and operation, the DCDinline D must be acclimatised to the ambient
conditions.
NOTICE
Ensure proper ESD handling throughout the installation. Errors that can be attributed
to electrostatic discharge will void warranty claims.
