Ext3-U-R - Kramer EXT3-U-KIT User Manual

EXT3-U-R

Inputs
Outputs
Ports
Extended USB
Extension Line
Extended RS-232
USB Charging
Indication LEDs
Power
Specifications are subject to change without notice at
EXT3-U-KIT – Technical Specifications
1 CAT
1 Stereo Analog Unbalanced Audio
4 USB
1 RS-232
Data Rate
Transmitted Data Bandwidth
Standards Compliance
Reach
Baud Rate
Max Total Current
Max Current Per Port
Front Panel
Consumption
Source
On an RJ-45 female connector for
extension line
On a 3.5mm mini jack for audio extension
On USB-A female connector for USB
devices extension
On a 3-pin terminal block for serial link
extension
Up to 480Mbps
Up to 300Mbps
1.1 and 2.0 USB
CAT 6A: Up to 100m (330ft)
CAT 5e: Up to 30m (100ft)
When using Kramer cables
9600
PSU-powered: 2.5A
PoC-powered: 0.5A
PSU-powered: 2A
PoC-powered: 0.5A
LINK LED and ON LED
12V DC, 1500mA
12V DC, 2A
www.kramerav.com
Kramer Electronics Ltd.
10
