Connecting To Ext3-U-Kit Via Rs-232; Wiring Rj-45 Connectors - Kramer EXT3-U-KIT User Manual

Alternatively, you can connect the power adapter the other way around: connect the
power adapter to the
the LINK RJ-45 ports.

Connecting to EXT3-U-KIT via RS-232

You can connect to
EXT3-U-KIT features an RS-232 3-pin terminal block connector allowing the RS-232 to
control EXT3-U-KIT.
Connect the RS-232 terminal block on the rear panel of
follows:
From the RS-232 9-pin D-sub serial port connect:
•
Pin 2 to the TX pin on the
block
•
Pin 3 to the RX pin on the
block
•
Pin 5 to the G pin on the
block

Wiring RJ-45 Connectors

This section defines the TP HDBT pinout, using a straight pin-to-pin cable with RJ-45
connectors.
It is recommended that the cable ground shielding be connected/soldered to the connector
shield.
EIA /TIA 568B
PIN Wire Color
1 Orange / White
2 Orange
3 Green / White
4 Blue
5 Blue / White
6 Green
7 Brown / White
8 Brown
EXT3-U-KIT – Connecting EXT3-U-KIT
EXT3-U-T and then to the mains so that
EXT3-U-KIT via an RS-232 connection
EXT3-U-KIT RS-232 terminal
EXT3-U-KIT RS-232 terminal
EXT3-U-KIT RS-232 terminal
Kramer Electronics Ltd.
EXT3-U-R
using, for example, a PC.
13
EXT3-U-KIT to a PC/controller, as
RS-232 Device
is powered via
EXT3-U-KIT
8
