System requirements

1 System requirements
Before starting the user should:
1. Install the preferred Integrated Development Environment (IDE).
2. ST-LINK/V2-1 driver will be installed automatically. In case of problem, the user can
proceed with manual installation of the driver, from toolchains install directory (further
details are available in
3. Download the STM32 Nucleo firmware from the www.st.com/stm32nucleo webpage.
4. Establish the connection with the STM32 Nucleo board, by connecting CN1 of the
Nucleo board to the USB port of the PC
connector CN1 inside the red circle).
The above steps will be detailed in the coming sections.
4/22
Section 3).

Figure 2. Connector CN1 for Nucleo 144 board

DocID025840 Rev 5
(Figure 2,Figure 3 and
UM1727
Figure 4 show the
