The DDI-10E is a dual line external dialer receiver module capable of processing a
variety of dialer protocols as noted in this manual. Only one DDI-10E may be connected
to a SYSTEM 3505, thus permitting two incoming phone lines to be monitored. Consult
Digitize for expansion beyond the two phone lines
The Digital Dialer interface option allows the SYSTEM 3505 to receive alarms through
the dial-up telephone network. The dialer option software provides conversion of coded
information from the receiver into the proper format for processing by the SYSTEM 3505
The DDI-10E is an dual-line external dialer receiver module (P/N 425196-0003 and
425196-0004) that will accept any pulsed dialer rate from 10 to 40 (37) BPS using 3x2 or
4x1 formats. Contact ID format will also operate with the DDI-10E. The DDI-10E will
process all dialer formats now available with the DDI-9E (except the unit cannot mix 3x2
formats with 4x1 formats.). Converting from the DDI-9E to the DDI-10E should not
require any setup changes for the existing formats.
The following dialer formats are supported by the DDI-10E:
A Silent Knight/Ademco slow, 10 BPS 3/1, 4/1, 4/2, non-extended format
B Silent Knight fast, 20 BPS 3/1, 4/1, 4/2, non-extended format
C Silent Knight/Ademco slow 10 BPS 3/1, extended format
D Silent Knight/Ademco fast 20 BPS 3/1, extended format
E Sescoa, Franklin, DCI, Vertex, 20 BPS 3/1, 4/1, 4/2, non-extended format
F Sescoa, Franklin, DCI, Vertex, 20 BPS 3/1, extended format
G Radionics 3/1, 4/2, non-extended format
H Radionics 3/1, 4/2, non-extended with parity format
I Radionics 3/1, extended format
J Radionics 3/1, extended with parity format
K SIA protocol by converting the corresponding SIA communications to fit
into CID protocol for presentation by the 3505
L Silent Knight, Contact ID (Ademco)
Future releases of the SYSTEM 3505 may include Modem CFSK, FBI Super Fast,
Acron, and Ademco High Speed. The DDI-10E can decode these, but the SYSTEM
3505 cannot process these formats at this time. Digitize will strive to implement as many
of these that are compatible with the nine-digit account number structure and the group
definitions currently in place. Future releases of new protocols will be free of charge.
The upgrades may be obtained by downloading the latest program from our website
when the formats are available.
