Alinx ACU4EV User Manual page 26

79 B26_L5_P
77 GND
79 B26_L1_P
81 B26_L1_N
83 GND
85 505_CLK2_P
87 505_CLK2_P
89 GND
91 505_CLK0_P
93 505_CLK0_N
95 GND
97 505_TX3_P
99 505_TX3_N
101 GND
103 505_RX3_P
105 505_RX3_N
107 GND
109 505_TX2_P
111 505_TX2_N
113 GND
115 505_RX2_P
117 505_RX2_N
119 GND
Pin assignment of board to board connector J31
J31 Pin Signal Name
1 B24_L10_P
3 B24_L10_N
5
7 B24_L6_P
9 B24_L6_N
11
13 B24_L5_P
15 B24_L5_N
17
26 / 30
ZYNQ Ultrascale + FPGA Core Board ACU4EV User Manual
D15
-
B15
A15
-
C21
C22
-
F23
F24
-
B23
B24
-
A25
A26
-
C25
C26
-
B27
B28
-
Pin Number
Y14
Y13
GND -
AC14
AC13
GND -
AD15
AD14
GND -
